EXC641W
CHEF — Cooker Electric
Parts for EXC641W
W0012753 MOTOR FAN COOLING
W0013602 THERMOSTAT OVEN
W0030765 THERMOMETER OVEN
$16.05
W0030846 GLOVE SILICONE
$25.90
W0042311 CHEF SIMPSON WESTINGHOUSE OVEN DOOR HINGE LH & RH
$76.50
W0046247 ELEMENT SPLIT/GRILL
W0046249 ELEMENT OVEN FAN 2200W
W0046406 CLIP MOUNTING ELEMENT
W0046869 SUPPORT HINGE DOOR
W0049202 GASKET CAVITY OVEN 1675MM
W0050298 HOLDER LAMP ASSY
W0050517 MOTOR FAN OVEN
W0053461 RACK GRILL INSERT
W0057184 SWITCH INF HEAT MDP 102 EA
W0062409 LIGHT INDICATOR RED
W0062455 CLOCK 2 BUTTON ORBI WITH RELAY
W0065076 CLIP BULB THERMOSTAT ELEC
$6.70
W0154309 CLEANER OVEN K2R 400G
W0154334 OYSTER TRAY FITS MOST GRILLS
$32.00
W0166032 LAMP 25W SES E14 300C CLEAR
$10.00
W0011993 NUT METRIC M10 X 0.75MM
$4.50
W0013730 BUMPER STOP BLK
$6.55
W0014018 SCREW #6 X 9.5MM PAN PHIL ZC
$4.50
W0035319 CONNECTOR BAR Q/CONN (2 TERM)
W0035793 DEFLECTOR GRILL ENAMEL BLUE
W0036210 SUPPORT SPLIT ELEMENT GRILL
W0036819 KNOB CHEF CLASSIC WHITE
W0036830 KNOB CLOCK 19MM WHITE
W0037434 PLATE-BACKING-MOTOR-FAN
W0037442 PLATE MTG SW E/CLOCK BLK 4H
W0037461 PLATE RETAINER GLASS CHROME
$6.60
W0037749 FAN IMPELLER 152MM
W0038080 COVER PLATE INSULATION
W0039205 DISH GRILL SMALL ENAM BLUE
W0039238 TRAY SCONE
$65.90
W0039423 PANEL INNER GR/DOOR ENAM BLUE
W0039630 PANEL DECK INTER
W0039632 PANEL BASE NO SLOTS
W0039682 PANEL TOP ELEC SEP GRILL
W0039764 PANEL SIDE SEP GRILL
W0039880 PANEL WIRING COVER SEP GRILL
W0041097 PANEL BAFFLE FAN (BLUE SPEC)
W0042310 HINGE DOOR GRILL N/S 6219570
W0042557 VENT TUBE ELECTRIC
W0042928 HANDLE BAR CLASSIC WHITE
W0044053 NUT M6 LH FAN MOTOR SEL
W0044544 FRAME FRONT ENAMEL BLUE SEP
W0047469 SCREW M4 X 5 PAN #2 PH SML HD
$4.50
W0047471 SCREW M5 X 30MM PAN #2PH ZC
$4.00
W0048063 END CAP HANDLE CLASSIC WHT
W0048232 WIRE INSULATION BACK FORMED
W0049219 SEAL GRILL 1272MM
W0049220 SEAL DOOR INNER GLASS 1630MM
W0049224 SEAL GRILL DOOR
$55.40
W0049227 SEAL O/D GLASS 49700 LN 1.5M
W0050619 CORD SERVICE 20A 1.4M
$33.00
W0052054 GLASS OUTER OV/DOOR WHT (ASSY)
W0052055 DOOR GRILL GLASS OUTER ASSY
W0052056 GLASS INNER OV/DOOR REFLECT
W0052080 PANEL CONTROL GLASS EXC641W
W0052575 CANOPY FAN
W0052930 SPACER HANDLE CLASSIC WHT
W0052932 SPACER INTERNAL HANDLE
W0052937 SPACER INTERNAL SHORT HANDLE
W0053459 RACK SIDE GRILL
W0053470 RACK SIDE OVEN LH/RH 5 POS
W0053476 SHELF OVEN
$58.90
W0054067 SHIELD VENT BAFFLE
W0054615 INSULATION OVEN BACK ELEC
W0054621 INSULATION GRILL TOP
W0054637 INSULATION OVEN WRAP OC98 D/F
W0054928 OVEN ENAM BLUE ELEC F/F SEP
W0055062 TAPE 3M #4930 0_6 X 12 X 540MM
W0055074 TAPE 3M #4930 0.6 X 12 80 ALU
W0056165 GRILL/BOX ENAMEL BLUE CLASSIC
W0057139 SWITCH AUXILLIARY EGO
W0057770 THERMOSTAT OVEN KEEP WARM EGO
W0059626 GROMMET CORD GRIP
W0059634 GROMMET SERVICE CORD
W0060090 SCREWS (INSTALL)QTY 2
W0062374 PANEL INNER OV/DOOR BLUE REMOV
W0064191 SCREW MUSH 3/16X3/8 MULTI CHR
W0064367 SCREW 3/16 X 1 PAN PHIL NI
W0064446 SCREW #10 X 3/4' PAN PH ZC AB
W0064477 SCREW CSK PH 6AB X 25MM BLK
$4.50
W0064532 SCREW #8 X 9/16 B/HD S/PT BKOX
$4.00
W0064563 SCREW ST 8 X 1/2
W0064617 SCREW NO 8 TC X 1/2 MUSH HD NI
W0064747 NUT HEX 3/16 BSW
$4.50
W0064939 WASHER 3/16 INT S/P ZC
$4.50
W0065207 WASHER CUP TERMINAL 3/16 H198
W0065209 WASHER 7/32 X 3/8 BR HI50W
W0065227 TIE CABLE PUSH MOUNT
W0065320 BUSH MOUNTING FRONT FRAME
W0065321 BUSHING SNAP SOLID BLK 22.2MM
W0065427 SCREW M5 X 9MM CSK (BLK ZC)
W0065456 NUT HEX M5 X 7.95AF X 4.5 TK
W0133494 CORD SERVICE 20AMP 1200MM
