BSK882320M — 944187873 03
AEG — Cooker Electric
Parts for BSK882320M
W0017827 OVER HEAT PROTECTION THEMO130C
$27.00
W0023173 ELEMENT HEATING ROUND 240V 240
$82.85
W0026342 FRAME OVEN LAMP SIDE
$26.35
W0026431 SPRING DAMPER MOTOR
$12.55
W0030821 TRAY BAKING
W0114339 BUSH, FIXING, OVEN D41116
$8.00
W0147344 LAMP HALOGEN BULB 25W G9 230V
W0274530 HANDLE INOX
$132.00
W0274627 GENERATOR STEAM
$221.00
W0274631 ELEMENT HEATING LOWER STEAM
$116.00
W0275423 MEAT THERMOMETER BLACK 480MM
$47.00
W0017741 STOPPER DOOR RUBBER HIGH-TEMP
$7.00
W0017773 DUCT EXHAUSST SLIDER ASSY DC
$41.55
W0017802 GASKET HEATING ELEMENT UPPER
W0017804 GRID RIGHT STEAM
$97.45
W0017805 GRID LEFT STEAM
$97.45
W0023154 BLADE FAN
$58.00
W0023193 GRILL INSERT 415X330X39.5MM
$51.00
W0023211 CLAMP CABLE 22 MM
$4.50
W0023219 SOCKET MEAT THERMOMETER BLACK
$77.00
W0023912 SCREW DOOR HAND M4 X 50 PKT 5
$12.00
W0024454 GASKET BOLS
$27.50
W0026334 NUT CONVECTION FAN M6L
$7.00
W0026523 ACTUATOR EXHAUST DUCT
$30.00
W0026955 PIPE INLET STEAM
$57.00
W0026979 GASKET STEAM INLET
$4.00
W0027110 ACTUATOR DESCALING PIPE 220-24
$65.00
W0027120 SHIELD BOTTOM HEATER STEAM
W0027135 INLET VALVE WATER
$142.00
W0027173 TUBE GENERATOR 35MM D15/D20
$11.00
W0027175 ELBOW STEAM INLET
W0027178 CLAMP HOSE 16 5MM
$5.50
W0027179 CLAMP HOSE 20MM
W0027180 CLAMP HOSE 12MM
W0027245 GASKET CONVECTION HEATER
$16.90
W0027375 TUBE CLIP D20MM
W0101122 CABLE HOLDER
W0103044 GASKET,OVEN LAMP, SIDE
$30.00
W0105621 CLIP.FIXING.ELECTRONIC.I=22.9M
W0105622 CLIP FIXING ELECTRONIC1=12 7MM
$4.50
W0114396 LAMP 40W 230V HALOGEN GLOBE G9
W0114504 DOOR OVEN INNER GLASS
W0114505 DOOR OVEN INNER GLASS
$105.00
W0114535 NUT UPPER HEATER
$5.50
W0114548 BOLT SIDE GRID
W0114561 GLASS, OVEN LAMP, HALOGEN
$12.00
W0114563 LAMP OVEN COMPLETE 40 W 240V
W0116500 KIT GASKET COVER CONVECTN FAN
$36.00
W0134346 GASKET OVEN LAMP TOP
$10.00
W0147319 TELESCOPIC RUNNER SET OF 2
W0147340 GLASS OVEN LAMP SIDE
$14.00
W0150372 CONVECTION MICRO-MOTOR.230V
W0154349 DISH STEAM SET
W0274104 TERMINAL BLOCK 3 POL
$18.25
W0274421 GASKETDESCALING PIPE
$6.00
W0274434 DESCALING PIPE SILI
$53.00
W0274436 PANEL BACK OVEN
$171.70
W0274439 TRIM DECORATIVET
$10.00
W0274440 GASKET, SENSOR
W0274441 GASKET, MICROSWITCH
$50.00
W0274452 CONECTION TUBE
W0274462 PAN DRIP 466X385X40 MM
$58.00
W0274484 PANEL SIDE LH
$189.20
W0274485 PANELSIDE RH
$189.20
W0274486 PANEL BOTTOM
$174.00
W0274487 PANEL TOP
$210.00
W0274506 TUBE WATER 340MM D16/D11
$20.00
W0274514 GLASS FRONT INOX 594 X 471MM
$242.00
W0274555 ADAPTOR DOOR HANDLE
$5.50
W0274574 CAP DRAWER STEAM INOX
$14.00
W0274577 TANK WATER ASSY STEAM VISION
$210.00
W0274613 FRAME FRONT
$60.05
W0274619 SWITCH ASSY DOOR
$68.00
W0274677 HARNESS PB - UI OVC5000
$23.50
W0274681 HOLDER HEATING ELEMENT
$5.00
W0274682 GASKET HOLDER
$5.00
W0274689 GRILL GRID 466X385 22
$90.00
W0274714 PIPE ELBOW 35MM
W0275062 LAMP ASSY 25W
$18.00
W0275092 KIT SCRW COVER
$10.00
W0275126 MOUNTING KIT WATER TANK
W0275338 SENSOR PT500 370MM
$65.00
W0275416 CONDENSER STEAM
$126.10
W0282109 DOOR COVER TOP BLACK NON PYRO
$23.30
W0282698 POWER BOARD OVC5000
$399.00
W0282699 GLASS SILK SCREEN 524X402MM
$79.85
W0282703 GASKET DOOR STEAM 1540MM
$67.00
W0282706 ELEMENT UPPER 240V 2300W
$137.00
W0282717 COVER CONVECTION FAN
$104.00
W0282737 HARNESS PB ACTUATOR
W0282739 HARNESS PB- -DOOR SWITCH
W0282747 HINGE STEAM 9.5 KG SOFT
$132.00
W0282750 HINGE STEEM 10KG SOFT
$126.00
W0282763 FAN COOLING ASSY 240V 22 W
$105.00
W0282769 HARNESS OVEN LAMP
$30.90
W0283211 BAR FIXING FAN COVER
$5.50
W0283241 TRIM DOOR BOTTOM STEAM
$16.45
