KPK742220M — 944066549 01
AEG — Cooker Electric
Parts for KPK742220M
W0023142 COVER TOP DOOR BLK
W0026274 MOTOR CONVEYOR 230V . .
$174.00
W0026435 OVEN WIRE SHELF CLIP
$5.50
W0026518 TOUCH PCB USER INTERFACE BOARD
$342.00
W0030821 TRAY BAKING
W0114339 BUSH, FIXING, OVEN D41116
$8.00
.JPG)
W0114562 LAMP OVEN COMPLETE G9 40W HALO
W0114583 HEATING ELEMENT, BOTTOM, 1000W
W0274530 HANDLE INOX
$132.00
W0274623 AEG OVEN DOOR LOCK WITH MOTOR PYRO
$99.00
W0274688 OVEN GRILL SHELF 466MM x 385MM
$64.00
W0275423 MEAT THERMOMETER BLACK 480MM
$47.00
W0017741 STOPPER DOOR RUBBER HIGH-TEMP
$7.00
W0017773 DUCT EXHAUSST SLIDER ASSY DC
$41.55
W0017858 HARNESS UI - POWER BOARD
$61.30
W0017939 PANEL TOP COVER
$44.95
W0022367 SWITCH THERMAL KLIXON 130C
W0022502 CATALYST
$60.00
W0023126 PANEL BASE
$41.80
W0023147 PCB MEAT THERMOMETER FPM
$99.00
W0023165 SCREW MOUNT 4.2MM X 9.5MM
$17.00
W0023181 SUPPORT, HINGE, LEFT
$29.50
W0023182 SUPPORT, HINGE, RIGHT
$29.50
W0023183 CHANNEL AIR UPPER
$72.55
W0023185 SUPPORT, CONNECTION BOX
$9.90
W0023193 GRILL INSERT 415X330X39.5MM
$51.00
W0023209 CLAMP CABLE 15x 16mm
$4.00
W0023210 CLAMP CABLE 22 x 23mm
$4.00
W0023211 CLAMP CABLE 22 MM
$4.50
W0023212 SHIELD, BOTTOM, HEATER, STEAM
$44.00
W0023219 SOCKET MEAT THERMOMETER BLACK
$77.00
W0024182 SCREW KIT BUSH HANDLE
$18.00
W0026025 KIT SPACE COMPENSATOR CARD .
$14.30
W0026249 DOOR GLASS 499X249MM .
$115.00
W0026250 DOOR GLASS 488X244MM
$57.00
W0026251 SIDE PANEL LEFT-RIGHT .
$77.00
W0026256 COVER CONVECTION FAN .
$66.00
W0026257 RACK OVEN SIDE R . .
$42.00
W0026258 RACK OVEN SIDE L
$40.00
W0026264 HEATING ELEMENT ROUND 240V 165
$137.00
W0026272 WHEEL CONVECTION FAN .
$54.00
W0026334 NUT CONVECTION FAN M6L
$7.00
W0026336 HARNESS DOOR LOCK POWER BOARD
$21.00
W0026337 CONNECTION BOX WITH CABLE 3X1
$77.00
W0026353 HARNESS DOOR SWITCH POWER BOAR
$174.05
W0026379 HARNESS POWER BOARD SIDEKICK
$26.85
W0026392 ELEMENT HEATING UPPER 1900W
$96.00
W0026395 GASKET ROUND 892 5MM
$42.00
W0026408 HARNES OVEN LAMP
$22.95
W0026523 ACTUATOR EXHAUST DUCT
$30.00
W0027100 MOUNTING SET FIXING
$30.00
W0027139 CARRIER STRUT BACK
$25.00
W0027244 GASKET DOOR
$92.00
W0027250 SENSOR PT100
$77.00
W0027303 ASSEMBLY COOLING FAN 240V 27W
$179.00
W0105621 CLIP.FIXING.ELECTRONIC.I=22.9M
W0105622 CLIP FIXING ELECTRONIC1=12 7MM
$4.50
W0114281 CLAMP CABLE
$15.40
W0114396 LAMP 40W 230V HALOGEN GLOBE G9
W0114514 POWER BOARD CONFIGURED OVC3000
W0114561 GLASS, OVEN LAMP, HALOGEN
$12.00
W0134350 NUT, HEATING ELEMENT, UPPER,M4
$5.50
W0134371 HARNESS POWER BOARD FPM
$60.50
W0274462 PAN DRIP 466X385X40 MM
$58.00
W0274555 ADAPTOR DOOR HANDLE
$5.50
W0274592 COVER UI
$14.95
W0274637 GLASS FRONT BLACK 594X332 MM
$136.00
W0274653 CONTROL PANEL,
$258.00
W0274675 GLASS SCREENED 524 X 263
W0274706 PANEL BACK OVEN
$55.00
W0275336 SPACER FLAT
W0275493 UI CONFIGURED ELECTRONIC
$290.05
W0361184 HINGE, 4P, 6.2 - 6.6kg
$32.00
W0361187 HINGE LONG, DAMPER,4P 6.2-6-7K
$120.00
