AGN81800C0 — 922784017 00
AEG — Freezer
Parts for AGN81800C0
W0159670 DRIER 12GM(XH9)DBLE/SGLE TAIL
W0017786 COVER, CARD ,CONTROL, COMPRESS
$30.00
W0017808 DOOR ,FREEZER 1684X538MM
$385.00
W0017872 MAGNETIC SEAL,7801, 514.5X1662
$137.00
W0017907 INTEGRATED DOOR MOUNTING KIT,
$68.05
W0017916 POWER CORD
$40.00
W0017930 CABLE HOLDER
$14.95
W0020502 BRACKET FIXING COMPRESSOR
$24.95
W0020503 FIXING BRACKET BOTTOM DOD
$20.00
W0020504 SCREW ADJUSTING DOD
$5.50
W0020505 FIXING BRACKET, COMPRESSOR
$24.95
W0020520 BUFFER COMPRESSOR 13X11.6MM
$4.00
W0020526 LEG
$4.95
W0020533 TRIMMING SIDE L=1790MM
$29.55
W0020534 HINGE, FLAP DOOR,RIGHT,7801
$17.00
W0020535 HINGE, FLAP DOOR,LEFT,7801
$17.00
W0020545 BEZEL ,TERMINAL BLOCK
$30.00
W0020546 COVER BRACKET STIRRUP DOD
$18.00
W0020547 HINGE COVER UPPER 7801
$14.85
W0020555 MAGNET DOOR .8X15MM
$11.00
W0020572 GLASS,FREEZER,402X315MM
$55.00
W0020576 TEMPLATE DOOR OUTER DOD
$7.00
W0020579 VALVE DRAIN WATER
$4.95
W0020580 ACCUMULATOR COLD 213X132MM
$44.95
W0020581 TERMINAL BLOCK
W0020672 SENSOR , FREEZER ,L=1600MM
$51.60
W0020677 BUFFER, VENTILATOR
$4.95
W0020680 EVAPORATOR ASSY, COMPLETE, 411
$1,033.60
W0020687 FAN, MES, 2000RPM, 12V
$170.05
W0020693 CARD, CONTROL, COMPRESSOR
$422.20
W0020694 COMPRESSOR, COMPLETE, HKK95VSD
$495.00
W0020695 TRAY EVAPORATION
$21.00
W0020696 PCB, DISPLAY
$170.05
W0020697 CABLE HOLDER ,COMPRESSOR
$14.95
W0020706 HEATER, EVAPORATOR, ASSEMBLY
$99.95
W0020888 PEG AIR CHANNEL 34MM
$4.95
W0020902 SHIELD, H 238MM
$24.95
W0020903 SHIELD,475MM
$40.00
W0020915 SUPPORT, POWER BOARD
$14.95
W0020918 AIR VENT GRID, FRONT, EVAPORAT
$17.00
W0020919 INSULATION, EVAPORATOR
$26.95
W0020930 CONTROL PANEL, ASSEMBLY, AEG
$49.00
W0020932 BOX FREEZER BOTTOM ASSEMBLY
$76.90
W0020933 DRAW FREEZER,COMPLETE,NEUTRAL,
$96.00
W0020935 AP DOOR,SILKSCREENED,174MM,''F
$35.00
W0020938 CONDENSER,467X1320.8MM
$120.00
W0020942 SCREW,COMPRESSOR,4X10 PH
$4.00
W0025347 MOUNT COMPRESSOR RUBBER
$10.00
W0026152 SCREW HINGE M5X16MM
$5.50
W0027016 COVER CONTROL PANEL FULL 7801
$46.00
W0027017 COVER CONTROL PANEL RIGHT 7801
$46.00
W0027018 COVER CONTROL PANEL LEFT 7801
$6.20
W0027061 TRIMMING UPPER
$26.60
W0027074 FIXING BRACKET DOOR
$30.00
W0027105 HINGE UPPER
$157.90
W0027106 HINGE LOWER
$221.95
W0027165 COVER TOP DOOR MAGNET DOD
$46.05
W0027167 SUPPORT MAGNET DOOR WHITE
$11.00
W0028975 PCB ELECTRONIC, ERF2001 PROGRA
$240.00
W0095900 SPACER. HINGE. HETTICH
W0096139 SUPPORT. EVAPORATOR
W0096140 VENTILATOR HOLDER
W0096141 SLEEVE. VENTILATOR
W0096145 THERMAL CUT-OUT
W0126308 ICE TRAY.105X225MM
