BGR400
BREVILLE — Small Appliance
Parts for BGR400
W0217990 PLATE HEIGHT CTRL KNOB SUPPORT
$4.50
W0217991 LINK
$11.20
W0217992 FRONT FOOT KNOB WASHER
$4.50
W0217993 ELEMENT SEAT
$4.50
W0218087 LOCK LEVER&SCREW FR HOT PLATE
$4.50
W0218088 SPRING FOR TILT BACK FEET
$4.50
W0218089 REAR ARM HINGE
$4.50
W0218154 PLATE HEIGHT CONTROL KNOB SEAT
$4.50
W0218155 HOT PLATE SEAT - BACK
$4.50
W0218247 PLATE HEIGHT CONTROL KNOB
$4.50
W0218397 PLATE RELEASE BUTTON
$11.20
W0218718 TEMPERATURE LINK ARM
$11.20
W0218719 KNOB FOR LINK ARM
$11.20
W0219239 TILT CONTROL KNOB
$12.00
W0219240 TEMPERATURE CONTROL KNOB
$11.20
W0219241 LAMP COVER - RED
$12.00
W0219242 LAMP COVER - GREEN
$12.00
W0219243 FRONT FOOT KNOB
$12.00
W0219616 INSTRUCTION BOOK
$12.95
W0219705 CORD WRAP
$13.98
W0219930 LEFT ARM HINGE SUPPORT
$16.60
W0220006 THERMAL CUT OUT
$11.20
W0220145 RIGHT ARM HINGE SUPPORT
$19.60
W0220242 THERMOSTAT
$20.10
W0220270 DRIP TRAY COMPLETE
$22.38
W0220368 HANDLE COMPLETE
$20.10
W0220499 TOP PLATE - INNER
$20.10
W0220500 BOTTOM PLATE - INNER
$20.10
W0220968 RIGHT ARM - PLATE HEIGHT GUIDE
$42.14
W0220969 LEFT ARM
$42.14
W0220990 ELEMENT
$42.96
W0221165 BOTTOM HOUSING COMPLETE
$54.54
W0221474 REMOVABLE FLAT PLATE
$58.50
W0221555 REMOVABLE RIBBED PLATE
$65.45
