CFE535WA — 940001793 18
CHEF — Cooker Electric

W0011400 DISH GRILL ENAM SEP GRILL

$68.20

W0011404 TRAY SCONE

$19.90

W0011909 HANDLE GRILL DISH

$9.90

W0011916 HANDLE DOOR

W0012254 ELEMENT C/HEAT 1800W SS321

W0012258 ELEMENT BOOST ASSY 800W - BIOS

W0012259 ELEMENT EGO 2000W 180DIA (HI)

W0012260 ELEMENT EGO 1000W 145DIA (HI)

$96.00

W0012861 DOOR OVEN INNER GLASS

W0012990 SPACER HANDLE BLK FRESCO

$10.25

W0013556 SWITCH GANG 7 POSITION EGO

W0013627 TRIM DOOR UPPER VENTED

W0013750 LENS INDICATOR LIGHT

$11.20

W0013858 KIT INDICATOR LIGHT FRESCO

W0014032 SCREW #8 X 45 PAN QUADREX

W0022807 HINGE DOOR OVEN

W0046262 ELEMENT EGO 1500W 145DIA (HI)

W0046266 ELEMENT 1000W CL/HEAT + EARTH

W0046406 CLIP MOUNTING ELEMENT

W0050309 LAMP

W0053461 RACK GRILL INSERT

W0053487 SHELF OVEN 473 X 378MM

W0057166 CHEF SIMPSON WESTINGHOUSE COOKTOP CONTROL SWITCH MP101

W0057210 SWITCH AUXILIARY T/STAT

W0057771 THERMOSTAT OVEN

W0060746 TIMER 60MIN 360 ACTION PEAPSA

W0147339 SEAL OVEN MODULAR PROFILE

W0166032 LAMP 25W SES E14 300C CLEAR

$10.00

W0011114 TERMINAL BLOCK W/EARTH BIOS

W0011200 SUPPORT ELEMENT BOOST

$10.35

W0011334 BRACKET ASSY ELEMENT 145MM

$12.60

W0011335 BRACKET ASSY ELEMENT 180MM

$18.00

W0011366 BRACKET HOB SUPPORT FRESCO

$9.90

W0011513 PANEL SIDE WHITE FRESCO

$89.30

W0011574 PANEL CONTROL SCREEN CFE535WA

$100.00

W0011693 PANEL SPLASHBACK 540 WHT FRESC

W0011845 HINGE GR DOOR 540 FRESCO PH2

$7.70

W0011846 HINGE GR DOOR 540 FREE FRESCO

$53.85

W0011993 NUT METRIC M10 X 0.75MM

$4.50

W0011994 NUT METRIC M12 X 1.00

$32.90

W0012166 WASHER LEAF SPRING 1/4

$4.00

W0012315 CLIP THERMOSTAT BIOS

$9.00

W0012417 SUPPORT COUNTER FRESCO

$7.05

W0012629 HARNESS 7 POS SW UR540 200MM

$17.15

W0012630 HARNESS 7 POS SW UR540 270MM

$18.00

W0012641 HARNESS 7 POS SW 710MM FRESCO

$18.00

W0012778 CORD SERVICE 10A

$10.05

W0012911 CANOPY GRILL ELEC FRESCO

$27.50

W0012986 INSULATOR HANDLE CHEF NGD

W0013260 SHIELD WIRING

$11.95

W0013263 SHIELD SPILLAGE

$17.45

W0013329 INSUL GRILL CANOPY TOP FRESCO

$10.95

W0013460 BRACE OVEN REAR 540 BIOS

$27.50

W0013731 BUMPER STOP GREY

$5.05

W0013768 HOB SOLID ENAMEL

$224.90

W0014019 SCREW #6X3.5X28 HILO PAN PH

$4.50

W0014022 SCREW #10-16X5/8 PAN PH2 BLK

$4.50

W0014026 SCREW #8 X 5/16 CSK #2PH AB BK

$4.50

W0014030 SCREW #8 X 8MM HEX/MULTI

$4.50

W0014033 SCREW #8 X 12 UNDERCUT PAN BLK

$4.50

W0014034 SCREW #8 X 1/2 MUSH #2PH AB BK

$4.50

W0014041 SCREW #8 x1/2 PH2 MUSH WASHER

$4.50

W0021594 WIRE HARNESS 535 FRESCO

W0022171 FOOT LEVELING

$16.35

W0027187 F/FRONT PAINT 540FC SEP GRILL

$67.90

W0029350 540 LOWER REAR BRACE

$12.60

W0029662 ANTI TILT PLATE

$15.65

W0030106 PNL OUT GR DR ASSY 540 SMALL P

W0030107 PNL OUT OV DR ASS 540 CHEF WHT

$78.90

W0035788 DEFLECTOR HEAT GRILL UC20

W0036207 RACK SIDE GRILL

W0036951 KNOB CONTROL WHT

W0037481 PLATE CVR TERM GAS 540 BIOS

W0037493 PLT MTG SWTCH MULTI 7 SGO FRES

W0038121 COVER CLEAN HEAT FULL GALV BIO

W0038745 BRACKET ANTI ROTATE SOLID UC20

W0039903 PANEL CABINET REAR (NO HOLE)

$28.00

W0041132 PANEL KICK WHITE

W0043118 PANEL REFLECTOR GRILL TOP

W0044830 FLUE DUCT OVEN ELEC 540 BIOS

W0045532 BOLT STABILISING

W0047180 SUPPORT GRILL ELEMENT

W0047469 SCREW M4 X 5 PAN #2 PH SML HD

$4.50

W0048099 END CAP CONTROL PANEL FRESCO L

W0048100 END CAP CONTROL PANEL FRESCO R

W0048312 HARNESS 7 POS SW 540MM FRESCO

W0052926 SPACER FOOT UC20

W0054645 INSULATION OVEN CABINET

W0054654 INSULATION GRILL BACK ELEVATED

W0054671 INSULATION OVEN REAR

$18.70

W0056177 GRILL BOX ENAM 540 BIOS

W0056768 LEG LEVELLING

$18.90

W0065458 NUT HEX M6

$4.50
