EBC5241W*35
CHEF — Cooker Electric
Parts for EBC5241W*35
W0011400 DISH GRILL ENAM SEP GRILL
$68.20
W0011830 HINGE DOOR GRILL
W0011831 HINGE DOOR GRILL
W0011909 HANDLE GRILL DISH
$9.90
W0012254 ELEMENT C/HEAT 1800W SS321
W0012255 ELEMENT GRILL 2200W SS321
W0012312 CLIP KICK PANEL
W0046253 ELEMENT RAD SML 6MM 1250W ZIM
W0046254 ELEMENT RAD LGE 8MM 2050W ZIM
W0046406 CLIP MOUNTING ELEMENT
W0046876 SUPPORT HINGE DOOR LH
W0046877 SUPPORT HINGE DOOR RH
$18.30
W0053461 RACK GRILL INSERT
W0053487 SHELF OVEN 473 X 378MM
W0057166 CHEF SIMPSON WESTINGHOUSE COOKTOP CONTROL SWITCH MP101
W0057771 THERMOSTAT OVEN
W0058476 RING DRESS SML
W0058477 RING DRESS LARGE
W0060746 TIMER 60MIN 360 ACTION PEAPSA
W0062420 LIGHT INDICATOR INC LENS
W0100889 CLIP SPRING KNOB
$9.15
W0011114 TERMINAL BLOCK W/EARTH BIOS
W0011344 BRACKET STABILITY BOLT 540
$12.60
W0011416 DOOR GRILL INNER
$99.00
W0011672 PANEL KICK WHITE 540
W0011993 NUT METRIC M10 X 0.75MM
$4.50
W0012315 CLIP THERMOSTAT BIOS
$9.00
W0012558 END CAP HANDLE WHT
W0013260 SHIELD WIRING
$11.95
W0013317 INSULATION GRILL CANOPY
$11.00
W0013730 BUMPER STOP BLK
$6.55
W0013731 BUMPER STOP GREY
$5.05
W0014018 SCREW #6 X 9.5MM PAN PHIL ZC
$4.50
W0014019 SCREW #6X3.5X28 HILO PAN PH
$4.50
W0014029 SCREW #8 X 1/2 MUSH PH#2 AB BK
W0014030 SCREW #8 X 8MM HEX/MULTI
$4.50
W0021285 LABEL DOOR GRILL
$4.50
W0035788 DEFLECTOR HEAT GRILL UC20
W0036207 RACK SIDE GRILL
W0036928 KNOB CHEF ELEC WHITE 7801 UC01
W0037466 PLATE ANTI TILT ASSY 540
$22.00
W0038121 COVER CLEAN HEAT FULL GALV BIO
W0038764 BRACKET INSULATION OVEN DOOR
W0039279 TRAY SPILL
$65.95
W0039453 DOOR OVEN INNER SOLID
$189.90
W0039516 PANEL OUTER OV/DOOR SOLID A/W
W0039549 DOOR GRILL OUTER
$99.90
W0039791 PANEL SIDE UPRIGHT BIOS MK2
W0039903 PANEL CABINET REAR (NO HOLE)
$28.00
W0040565 PNL CNT FRONT SCR 5241 BIOS
$121.00
W0040940 PANEL SPLASHBACK WHT PLAIN
W0041113 PANEL LOWER BRACE 540
W0042919 HANDLE DOOR WHT
W0043116 REFLECTOR GRILL ELEC F/C UC20
W0044569 FRAME FRONT
$79.20
W0044830 FLUE DUCT OVEN ELEC 540 BIOS
W0045532 BOLT STABILISING
W0047139 INSULATOR SPILL/SWITCH
W0047180 SUPPORT GRILL ELEMENT
W0047469 SCREW M4 X 5 PAN #2 PH SML HD
$4.50
W0050003 SEAL OVEN BIOS
W0052578 CANOPY GRILL ELEC UC20
W0052926 SPACER FOOT UC20
W0054077 SHIELD VENT SPILLAGE GAS UC20
W0054643 INSUL GRILLCANOPY FRONT UC20
W0054645 INSULATION OVEN CABINET
W0054646 INSULATION OVEN BACK BIOS
W0054944 OVEN ENAMELE FRM CON N/L BIOS
W0056177 GRILL BOX ENAM 540 BIOS
W0056274 BRACE OVEN REAR 540 BIOS
W0056768 LEG LEVELLING
$18.90
W0056770 FOOT LEVELLING UPRIGHT
W0061890 HOB ENAM RADIANT FLAT UC20
W0064447 SCREW #10 X 11.5 PAN PH 'Z' P
W0064532 SCREW #8 X 9/16 B/HD S/PT BKOX
$4.00
W0064625 SCREW #8X20 TYP 17 PT TORX BLK
W0064868 WASHER 3/16 X 3/8 ALUM
W0065427 SCREW M5 X 9MM CSK (BLK ZC)
