EGC653S
CHEF — Cooker Electric

W0012753 MOTOR FAN COOLING

W0046238 ELEMENT CLEAN HEAT OVEN 1500W

W0046244 ELEMENT OVEN BOOST 800W

W0046248 ELEMENT GRILL 1800W (EARTHED)

W0046249 ELEMENT OVEN FAN 2200W

W0046406 CLIP MOUNTING ELEMENT

W0046869 SUPPORT HINGE DOOR

W0049202 GASKET CAVITY OVEN 1675MM

W0050298 HOLDER LAMP ASSY

W0050517 MOTOR FAN OVEN

W0053453 SHELF OVEN 459 X 360MM

$77.00

W0057198 SWITCH INFINITE MPA 101

W0065076 CLIP BULB THERMOSTAT ELEC

$6.70

W0166032 LAMP 25W SES E14 300C CLEAR

$10.00

W0011993 NUT METRIC M10 X 0.75MM

$4.50

W0012970 SPACER HANDLE

W0013313 INSULATION OVEN WRAP ELEC SGUB

$23.40

W0013730 BUMPER STOP BLK

$6.55

W0013937 MAGNET GRILL DOOR

$8.80

W0014018 SCREW #6 X 9.5MM PAN PHIL ZC

$4.50

W0014023 SCREW #8 X 5/8 CSK #2PH AB BK

$4.50

W0014028 SCREW NO 8 X 8MM W/HD PD NI

$4.50

W0035319 CONNECTOR BAR Q/CONN (2 TERM)

W0036201 SUPPORT ELEMENT GRILL

W0036858 KNOB PUSH/PUSH S/S

W0037434 PLATE-BACKING-MOTOR-FAN

W0037692 SLIDE GRILL (ASSY) SGUB

W0037749 FAN IMPELLER 152MM

W0038077 COVER CLEAN HEAT

W0038104 COVER G/DISH S/LESS LGE PREM

W0038732 BRACKET SUPP REAR GRILL SGUB

W0039200 DISH GRILL BLK OVEN

$50.00

W0039235 TRAY SHELF F/WIDTH ENAM

W0039427 PANEL INNER GR/DOOR ENAM BLK

W0039439 DOOR OVEN INNER PANEL & GLASS

W0039630 PANEL DECK INTER

W0039632 PANEL BASE NO SLOTS

W0039636 PANEL COVER INSULATION

W0039685 PANEL TOP SGUB

W0039767 PANEL SIDE SCUB

W0039881 PANEL WIRING COVER U/B

W0040371 PANEL CONTROL EGC653S

W0041039 PANEL BAFFLE FAN (BLK SPEC)

W0042946 HANDLE OV/DOOR BAR PREM S/S

W0043810 LIGHT INDICATOR RED 170DEG C

W0043814 LIGHT INDIC NEON 240V 600MM

W0044053 NUT M6 LH FAN MOTOR SEL

W0044062 NUT RETAINING

$7.70

W0044550 FRAME FRONT ENAMEL BLACK SGUB

W0044823 FLUE BOX OVEN ELEC

W0045141 ANGLE SLIDE LH GRILL SGUB

W0045142 SLIDE GRILL RH

W0045361 WASHER BUSH IGNITION

W0047142 RING O HANDLE

W0047180 SUPPORT GRILL ELEMENT

W0047469 SCREW M4 X 5 PAN #2 PH SML HD

$4.50

W0048088 END CAP HANDLE PREMIUM S/S

W0048232 WIRE INSULATION BACK FORMED

W0049225 SEAL DOOR INNER GLASS

W0050619 CORD SERVICE 20A 1.4M

$33.00

W0052575 CANOPY FAN

W0052941 SPACER HANDLE SGUB S/S

W0052942 SPACER COLLAR RETRACT KNOB

W0052943 SPACER COLLAR DRILLED

W0053454 RACK SIDE OVEN LH 5 POS

W0053462 RACK SIDE OVEN RH 5 POS

$11.70

W0054067 SHIELD VENT BAFFLE

W0054615 INSULATION OVEN BACK ELEC

W0054630 INSULATION GRILL TOP SCUB

W0054635 INSULATION GRILL DOOR

W0054636 INSULATION GRILL COMPT BACK

W0054884 OVEN ENAM F/F ELEC GIO

W0055068 TAPE V1510 10 X 3_2 X 594MM

W0055079 TAPE V1510 10 X 3.2 X 110MM

W0056163 GRILL/BOX ENAMEL BLACK SCUB

W0057207 SWITCH M/FUNCTION 5 QIK HEAT

W0057754 SWITCH THERMAL CUT OUT 70 DEG

W0057755 SWITCH THERMAL CUT OUT 120 DEG

W0057770 THERMOSTAT OVEN KEEP WARM EGO

W0059634 GROMMET SERVICE CORD

W0060090 SCREWS (INSTALL)QTY 2

W0060743 BUTTON CLOCK S/S 3-B DIEHL CHE

W0061685 LENS BRACKET DIEHL CHEF

W0062400 PANEL OUTR OV/DR PREM CHEF S/S

W0062402 PANEL OUTER GR/DOOR PREM S/S

W0064367 SCREW 3/16 X 1 PAN PHIL NI

W0064446 SCREW #10 X 3/4' PAN PH ZC AB

W0064527 SCREW NO 8 X 12 MM PD

$4.50

W0064532 SCREW #8 X 9/16 B/HD S/PT BKOX

$4.00

W0064533 SCREW #8 X 3/8 MUSH AB

$4.50

W0064589 SCREW 3/16X25MM PAN PH TRILOB

$4.00

W0064590 SCREW 3/16X30MM PAN PH TRILOB

W0064617 SCREW NO 8 TC X 1/2 MUSH HD NI

W0064747 NUT HEX 3/16 BSW

$4.50

W0064939 WASHER 3/16 INT S/P ZC

$4.50

W0065227 TIE CABLE PUSH MOUNT

W0065320 BUSH MOUNTING FRONT FRAME

W0065321 BUSHING SNAP SOLID BLK 22.2MM

W0065427 SCREW M5 X 9MM CSK (BLK ZC)

W0105524 CLOCK 3 BTN EASYTIME W/RELA
