EGC653W
CHEF — Cooker Electric
Parts for EGC653W
W0012753 MOTOR FAN COOLING
W0046238 ELEMENT CLEAN HEAT OVEN 1500W
W0046244 ELEMENT OVEN BOOST 800W
.JPG)
W0046248 ELEMENT GRILL 1800W (EARTHED)
.JPG)
W0046249 ELEMENT OVEN FAN 2200W
.JPG)
W0046406 CLIP MOUNTING ELEMENT
.JPG)
W0046869 SUPPORT HINGE DOOR
W0049202 GASKET CAVITY OVEN 1675MM
.JPG)
W0050298 HOLDER LAMP ASSY
.JPG)
W0050517 MOTOR FAN OVEN
.JPG)
W0053453 SHELF OVEN 459 X 360MM
$77.00
.JPG)
W0057198 SWITCH INFINITE MPA 101
W0062412 LIGHT INDICATOR INC RED LENS
W0062420 LIGHT INDICATOR INC LENS
.JPG)
W0065076 CLIP BULB THERMOSTAT ELEC
$6.70
W0100889 CLIP SPRING KNOB
$9.15
W0166032 LAMP 25W SES E14 300C CLEAR
$10.00
W0011993 NUT METRIC M10 X 0.75MM
$4.50
W0012970 SPACER HANDLE
W0013313 INSULATION OVEN WRAP ELEC SGUB
$23.40
W0013730 BUMPER STOP BLK
$6.55
W0013937 MAGNET GRILL DOOR
$8.80
W0014018 SCREW #6 X 9.5MM PAN PHIL ZC
$4.50
W0014023 SCREW #8 X 5/8 CSK #2PH AB BK
$4.50
W0014028 SCREW NO 8 X 8MM W/HD PD NI
$4.50
W0035319 CONNECTOR BAR Q/CONN (2 TERM)
W0036201 SUPPORT ELEMENT GRILL
W0036848 KNOB CONTROL WHT
W0037434 PLATE-BACKING-MOTOR-FAN
W0037460 PLATE MTG SWITCH BLK DIEHL CHE
W0037692 SLIDE GRILL (ASSY) SGUB
W0037749 FAN IMPELLER 152MM
W0038077 COVER CLEAN HEAT
W0038104 COVER G/DISH S/LESS LGE PREM
W0038732 BRACKET SUPP REAR GRILL SGUB
W0039200 DISH GRILL BLK OVEN
$50.00
W0039235 TRAY SHELF F/WIDTH ENAM
W0039427 PANEL INNER GR/DOOR ENAM BLK
W0039439 DOOR OVEN INNER PANEL & GLASS
W0039630 PANEL DECK INTER
W0039632 PANEL BASE NO SLOTS
W0039636 PANEL COVER INSULATION
W0039685 PANEL TOP SGUB
W0039767 PANEL SIDE SCUB
W0039881 PANEL WIRING COVER U/B
W0041039 PANEL BAFFLE FAN (BLK SPEC)
W0042948 HANDLE BAR PREM WHITE
W0044053 NUT M6 LH FAN MOTOR SEL
W0044550 FRAME FRONT ENAMEL BLACK SGUB
W0044823 FLUE BOX OVEN ELEC
W0045141 ANGLE SLIDE LH GRILL SGUB
W0045142 SLIDE GRILL RH
W0047140 RING O HANDLE
W0047142 RING O HANDLE
W0047180 SUPPORT GRILL ELEMENT
W0047469 SCREW M4 X 5 PAN #2 PH SML HD
$4.50
W0048089 END CAP HANDLE PREMIUM WHT
W0048232 WIRE INSULATION BACK FORMED
W0049225 SEAL DOOR INNER GLASS
W0050619 CORD SERVICE 20A 1.4M
$33.00
W0052164 PANEL CONTR GLASS & CLIP ASSY
W0052180 DOOR GRILL OUTER WHT
W0052575 CANOPY FAN
W0052940 SPACER HANDLE SGUB GLASS
W0053454 RACK SIDE OVEN LH 5 POS
W0053462 RACK SIDE OVEN RH 5 POS
$11.70
W0054067 SHIELD VENT BAFFLE
W0054615 INSULATION OVEN BACK ELEC
W0054630 INSULATION GRILL TOP SCUB
W0054635 INSULATION GRILL DOOR
W0054636 INSULATION GRILL COMPT BACK
W0054884 OVEN ENAM F/F ELEC GIO
W0055078 TAPE #506SL310 8 X 560 X .6MM
W0056163 GRILL/BOX ENAMEL BLACK SCUB
W0057207 SWITCH M/FUNCTION 5 QIK HEAT
W0057754 SWITCH THERMAL CUT OUT 70 DEG
W0057755 SWITCH THERMAL CUT OUT 120 DEG
W0057770 THERMOSTAT OVEN KEEP WARM EGO
W0059634 GROMMET SERVICE CORD
W0060090 SCREWS (INSTALL)QTY 2
W0060742 BUTTON WHT
W0062403 PANEL OUTR OV/DR PREM CHEF WHT
W0064367 SCREW 3/16 X 1 PAN PHIL NI
W0064446 SCREW #10 X 3/4' PAN PH ZC AB
W0064450 SCREW COMB NIBS HD ZP 3/16X28
W0064527 SCREW NO 8 X 12 MM PD
$4.50
W0064532 SCREW #8 X 9/16 B/HD S/PT BKOX
$4.00
W0064533 SCREW #8 X 3/8 MUSH AB
$4.50
W0064590 SCREW 3/16X30MM PAN PH TRILOB
W0064747 NUT HEX 3/16 BSW
$4.50
W0064939 WASHER 3/16 INT S/P ZC
$4.50
W0065227 TIE CABLE PUSH MOUNT
W0065320 BUSH MOUNTING FRONT FRAME
W0065321 BUSHING SNAP SOLID BLK 22.2MM
W0065427 SCREW M5 X 9MM CSK (BLK ZC)
W0105524 CLOCK 3 BTN EASYTIME W/RELA
