EOC647W*01
CHEF — Cooker Electric

Parts for EOC647W*01

W0011297 BLADE FAN
W0011916 HANDLE DOOR
W0011995 NUT M6 LH FAN MOTOR
W0012256 ELEMENT GRILL/BOOST 3000W
W0012262 ELEMENT FAN RING 2200W
W0012263 ELEMENT C/HEAT 1800W NO EARTH
$95.00
W0013564 SWITCH MULTI 5
W0013596 SWITCH THERMAL CUT OUT 190 DEG
W0013750 LENS INDICATOR LIGHT
$11.20
W0014025 SCREW #8-10X35 PAN PH2 P/B BK
$4.50
W0014032 SCREW #8 X 45 PAN QUADREX
W0022966 HINGE DOOR
W0046406 CLIP MOUNTING ELEMENT
W0050309 LAMP
W0050403 MOTOR FAN OVEN
W0052258 DOOR OVEN INNER GLASS
W0052585 CANOPY FAN ASSY U/B NGD
W0053487 SHELF OVEN 473 X 378MM
W0057771 THERMOSTAT OVEN
W0058493 TRIM DOOR UPPER VENTED
W0114261 CLOCK 3 BUTTON 3 W/RELAY
W0166032 LAMP 25W SES E14 300C CLEAR
$10.00
No image available
W0011114 TERMINAL BLOCK W/EARTH BIOS
No image available
W0011262 PLATE MOUNTING SWITCH
$14.90
No image available
W0011264 PLATE CVR TERM ELEC BIOS
$13.85
No image available
W0011321 COVER BASE PANEL SHIELD BIOS
$29.70
No image available
W0011484 PANEL SIDE RH
$28.00
No image available
W0011485 PANEL SIDE LH
$27.50
No image available
W0011559 PANEL CONTROL & CLIPS
$99.00
No image available
W0011666 COVER FAN & ELEMENT
$95.75
No image available
W0011856 SUPPORT ELEMENT
No image available
W0012083 FLUE OVEN VENT ELEC U/B NGD
$16.50
No image available
W0012315 CLIP THERMOSTAT BIOS
$9.00
No image available
W0012562 MOUNT CAP F/FRAME R/H NGD
$5.80
No image available
W0012563 MOUNT CAP F/FRAME L/H NGD
$7.55
No image available
W0012972 SPACER HANDLE GLS DR SOD BIOS
No image available
W0013260 SHIELD WIRING
$11.95
No image available
W0013625 FRAME CONTROL PANEL
No image available
W0013730 BUMPER STOP BLK
$6.55
No image available
W0014018 SCREW #6 X 9.5MM PAN PHIL ZC
$4.50
No image available
W0014019 SCREW #6X3.5X28 HILO PAN PH
$4.50
No image available
W0014021 SCREW #10 X 14.5 PAN PH 'Z' PT
No image available
W0014023 SCREW #8 X 5/8 CSK #2PH AB BK
$4.50
No image available
W0014029 SCREW #8 X 1/2 MUSH PH#2 AB BK
No image available
W0014030 SCREW #8 X 8MM HEX/MULTI
$4.50
No image available
W0014079 BUSH MOUNT F/FRAME NGD
$7.25
No image available
W0036949 KNOB CONTROL WHT
No image available
W0038118 COVER RETAINING LATCH
$10.95
No image available
W0038121 COVER CLEAN HEAT FULL GALV BIO
No image available
W0039208 DISH GRILL ENAM 540 BIOS
No image available
W0039580 DOOR OVEN OUTER WHT
No image available
W0039639 BASEPLATE
No image available
W0039640 PANEL UPPER
No image available
W0039686 PANEL CHASSIS TOP
$27.50
No image available
W0039894 PANEL CABINET REAR
$27.50
No image available
W0042634 CHANNEL FRONT UB RH NGD
No image available
W0042636 CHANNEL FRONT UB LH NGD
No image available
W0042768 PLUG DOME MDP16
No image available
W0043827 LIGHT INDICATOR RED
$14.90
No image available
W0044572 FRAME FRONT PAINTED ELE UB NGD
No image available
W0047143 INSULATOR HANDLE GLASS SIMPSON
No image available
W0047469 SCREW M4 X 5 PAN #2 PH SML HD
$4.50
No image available
W0050008 GASKET CAVITY OVEN NOTCHED
No image available
W0053490 RACK GRILL INSERT
No image available
W0053492 RACK GRILL DISH
No image available
W0054645 INSULATION OVEN CABINET
No image available
W0054671 INSULATION OVEN REAR
$18.70
No image available
W0054972 OVEN ENAM ELEC MF5 FRM NGD
No image available
W0056272 BRACE OVEN REAR BI BIOS
No image available
W0057755 SWITCH THERMAL CUT OUT 120 DEG
No image available
W0060744 BUTTON BLK
$12.60
