EXC617W — 944031489 16
CHEF — Cooker Electric
Parts for EXC617W
W0011401 DISH GRILL ENAM F/WIDTH BIOS
W0011916 HANDLE DOOR
W0012255 ELEMENT GRILL 2200W SS321
W0012258 ELEMENT BOOST ASSY 800W - BIOS
W0012840 DOOR GRILL INNER GLASS
W0013590 SWITCH THERMAL CUT OUT 145 DEG
W0013596 SWITCH THERMAL CUT OUT 190 DEG
W0013619 TRIM DOOR LOWER
W0013750 LENS INDICATOR LIGHT
$11.20
W0014025 SCREW #8-10X35 PAN PH2 P/B BK
$4.50
W0014032 SCREW #8 X 45 PAN QUADREX
W0022966 HINGE DOOR
W0023085 HINGE DOOR GRILL
$64.25
W0046406 CLIP MOUNTING ELEMENT
W0050309 LAMP
W0052258 DOOR OVEN INNER GLASS
W0052585 CANOPY FAN ASSY U/B NGD
W0053487 SHELF OVEN 473 X 378MM
W0057166 CHEF SIMPSON WESTINGHOUSE COOKTOP CONTROL SWITCH MP101
W0057210 SWITCH AUXILIARY T/STAT
W0057771 THERMOSTAT OVEN
W0058493 TRIM DOOR UPPER VENTED
W0060746 TIMER 60MIN 360 ACTION PEAPSA
W0147339 SEAL OVEN MODULAR PROFILE
W0166032 LAMP 25W SES E14 300C CLEAR
$10.00
W0011114 TERMINAL BLOCK W/EARTH BIOS
W0011260 PLATE MOUNTING SWITCH
$14.95
W0011264 PLATE CVR TERM ELEC BIOS
$13.85
W0011563 PANEL CONTROL & CLIPS
$128.00
W0011856 SUPPORT ELEMENT
W0011993 NUT METRIC M10 X 0.75MM
$4.50
W0012083 FLUE OVEN VENT ELEC U/B NGD
$16.50
W0012315 CLIP THERMOSTAT BIOS
$9.00
W0012562 MOUNT CAP F/FRAME R/H NGD
$5.80
W0012563 MOUNT CAP F/FRAME L/H NGD
$7.55
W0012972 SPACER HANDLE GLS DR SOD BIOS
W0013260 SHIELD WIRING
$11.95
W0013320 INSULATION OVEN BACK DUO BIOS
$11.00
W0013625 FRAME CONTROL PANEL
W0013730 BUMPER STOP BLK
$6.55
W0014018 SCREW #6 X 9.5MM PAN PHIL ZC
$4.50
W0014019 SCREW #6X3.5X28 HILO PAN PH
$4.50
W0014021 SCREW #10 X 14.5 PAN PH 'Z' PT
W0014023 SCREW #8 X 5/8 CSK #2PH AB BK
$4.50
W0014029 SCREW #8 X 1/2 MUSH PH#2 AB BK
W0014030 SCREW #8 X 8MM HEX/MULTI
$4.50
W0014079 BUSH MOUNT F/FRAME NGD
$7.25
W0027199 FRAME FRONT ENAM ELE SGWO NGP
$79.20
W0036213 SUPPORT ELEMENT GRILL
W0036949 KNOB CONTROL WHT
W0038118 COVER RETAINING LATCH
$10.95
W0038121 COVER CLEAN HEAT FULL GALV BIO
W0039572 DOOR GRILL GLASS OUTER WHT
W0039581 DOOR OVEN OUTER WHT
$108.00
W0039639 BASEPLATE
W0039640 PANEL UPPER
W0039686 PANEL CHASSIS TOP
$27.50
W0039691 PANEL GRILL TOP SGWO ENAM BIOS
W0042640 CHANNEL FRONT SGWO RH NGD
W0042642 CHANNEL FRONT SGWO LH NGD
W0043827 LIGHT INDICATOR RED
$14.90
W0046264 ELEMENT 1000W CLEAN HEAT
W0047143 INSULATOR HANDLE GLASS SIMPSON
W0047469 SCREW M4 X 5 PAN #2 PH SML HD
$4.50
W0052948 SPACER CONTROL PANEL BIOS
$6.00
W0053490 RACK GRILL INSERT
W0053502 RACK SIDE GRILL LH/RH
$40.00
W0054645 INSULATION OVEN CABINET
W0054663 INSULATION GRILL SGWO BIOS
W0054671 INSULATION OVEN REAR
$18.70
W0054974 OVEN ENAM FORM BOOST NGD
W0056173 GRILL BOX ENAM DEEP 600UP
W0056272 BRACE OVEN REAR BI BIOS
W0057755 SWITCH THERMAL CUT OUT 120 DEG
