EVE636DSD — 944031800 00
ELECTROLUX — Cooker Electric
Parts for EVE636DSD
W0011995 NUT M6 LH FAN MOTOR
.JPG)
W0012256 ELEMENT GRILL/BOOST 3000W
W0012262 ELEMENT FAN RING 2200W
.JPG)
W0012326 CLIP MOUNTING ELEMENT
W0012886 GLASS OV DR IN WEST FORTE
.JPG)
W0013590 SWITCH THERMAL CUT OUT 145 DEG
W0013619 TRIM DOOR LOWER
W0013970 RELAY 30A SINGLE POLE 240V
.JPG)
W0022968 HINGE DOOR
.JPG)
W0030130 TRIM DOOR TOP CAP NGD
W0030434 SEAL OVEN MODULAR PROFILE
W0032275 LAMP 25W 240V G9 PYRO HALOPIN
_1.JPG)
W0050403 MOTOR FAN OVEN
.JPG)
W0052585 CANOPY FAN ASSY U/B NGD
W0271174 IMPELLER OVEN FAN 160 MM
W0274167 SENSOR TEMPERATURE PT500 575MM
W0275063 LAMP OVEN ROUND PYRO BIOS
W0275069 SENSOR TEMPERATURE PT500 980MM
$44.05
W0275423 MEAT THERMOMETER BLACK 480MM
$47.00
W0282043 SPACER HANDLE GLS DR
W0284628 POWERBOARD - OVC2000 DUAL CAV
W0011114 TERMINAL BLOCK W/EARTH BIOS
W0011264 PLATE CVR TERM ELEC BIOS
$13.85
W0011345 BRACKET KRONOS PROBE MOUNT BIO
$12.60
W0011358 BRACKET DOOR SWITCH DO NGD
$6.60
W0011667 PANEL FAN COVER CAT BIOS
W0011856 SUPPORT ELEMENT
W0012562 MOUNT CAP F/FRAME R/H NGD
$5.80
W0012563 MOUNT CAP F/FRAME L/H NGD
$7.55
W0012631 WIRE HARNESS BIOS DOOR SWITCH
W0012643 HARNESS K2 INTERFACE 783/883
$4.50
W0012849 DOOR OVEN INNER GLASS MIDDLE
W0013260 SHIELD WIRING
$11.95
W0013461 BRACE OVEN REAR B/I BIOS
$24.85
W0013570 LEVER SWITCH DOOR LIGHT MICRO
$42.95
W0013578 SWITCH DOOR LIGHT ASSY NGD
$24.70
W0013625 FRAME CONTROL PANEL
W0013631 TRIM DOUBLE WALL OVEN PAINTED
W0013730 BUMPER STOP BLK
$6.55
W0014019 SCREW #6X3.5X28 HILO PAN PH
$4.50
W0014030 SCREW #8 X 8MM HEX/MULTI
$4.50
W0014034 SCREW #8 X 1/2 MUSH #2PH AB BK
$4.50
W0014041 SCREW #8 x1/2 PH2 MUSH WASHER
$4.50
W0027198 F/FRONT PAINT DO LWR SW NGP
$75.00
W0029801 PLUNGER DOOR SWITCH NGD
$7.05
W0030433 RECEPTACLE ASSY FOOD PROBE
$30.95
W0030490 PANEL TOP
$44.90
W0030494 PANEL BASE BIOS 0.5MM
$38.35
W0030606 INSULATION OVEN BACK - KNAUF
$15.55
W0038118 COVER RETAINING LATCH
$10.95
W0039640 PANEL UPPER
W0042657 CHANNEL FRONT DWO ASSY RH NGP
W0042658 CHANNEL FRONT DWO ASSY LH NGP
W0059827 DUCT DOUBLE OVEN ASSY BIOS
W0059835 DUCT DOUBLE OVEN ASSY
W0064627 SCREW #4 X16 T25 W/HD PHIL#2
W0103157 SWITCH DOOR LIGHT MICRO
W0134397 RUNNER TELESCOPIC KIT OF 2
W0154101 DISH BAKING CAST BIOS
W0275331 SCREW M4 X 50 PAN GENESYS
$5.50
W0275784 CONTROL IOI GEN3 PRG EVE636SD
W0283258 FLUE DUCT OVEN DUO BIOS
$5.25
W0283403 WIRE HARNESS OVC2K FPM MODUL
$11.65
W0283441 COVER CLEAN HEAT
$9.65
W0283475 SPACER HANDLE E100 DARK S/S
W0283479 HANDLE PAD E100
$4.50
W0283485 RACK SIDE OVEN EASY RH E100
W0283486 RACK SIDE OVEN EASY LH E100
W0283519 PNL OV DR OUT AS 36 E100
W0283532 RACK SHELF OVEN ELUX E100
W0283545 INSULATION OVEN WRAP - KNAUF
W0283555 PANEL SIDE D/O LH E100
W0283556 PANEL SIDE D/O RH E100
W0283612 F/FRONT ENAM ELE UB E100
W0283646 PANEL COVER WIRE D/O 36MM
W0283732 HOLDER LAMP SIDE ASSY G9 PYRO
W0283803 OVC2000 FPM INTERFACE BOARD
$20.35
W0284064 CLIP SIDEGRIDS
$4.50
W0284238 FOOD PROBE MODULE OVC2000
$42.95
W0284338 HANDLE DOOR E100 DARK S/S
$50.00
W0284351 DISH GRILL ENAM E100
$78.10
W0284352 TRAY BAKING PREMIUM ENAM E100
$58.05
W0284423 RACK PACK ELUX
$109.50
W0284441 ELEMENT BASE 1000W E100
W0284448 GLASS & TAPE EVE636DSD
$130.00
