ESF65060W — 911915620 02
ELECTROLUX — Dishwasher
Parts for ESF65060W
W0015721 MOUNT PRESSURE SWITCH
$50.00
W0015729 TUBE PRESURE SWICH LEVEL 525MM
$21.00
W0019083 MANIFOLD OUTER
W0023474 HINGE KIT DOOR LH/RH
$135.05
W0025858 ROLLER KIT LOWER PKT 8
W0072845 GASKET DOOR 1730MM
W0090295 CLIP BASKET STOP FRONT
$11.15
W0090412 COUPLING MANIFOLD LIGHT GREY
W0090747 GASKET DOOR LOWER BLK L=550
$31.00
W0090786 SUMP
$121.00
.JPG)
W0090799 SWITCH PRESSURE LEVEL 65/45
.JPG)
W0090800 SWITCH PRESSURE SAFETY 123/98
W0116461 CLIP FIXING STUD (PKT 4)
$5.50
W0128335 ELEMENT INLINE 230V/2000W 32MM
.JPG)
W0128336 FILTER DRAIN
W0128355 MOTOR WASH 2800RPM
$237.00
W0149911 STOP BASKET REAR DK GREY
W0015142 SWITCH MAIN ON/OFF
W0015341 PIPE UNION HEATING ELEMENT
$18.90
W0015730 DISHWASHER BASKET UPPER DK GRY
W0015742 RAIL BASKET UPPER
W0015751 CORD POWER AUST/NZ 10A
$40.00
W0018981 FOOT ADJUSTABLE
$18.90
W0018988 LATCH DOOR LOCK
W0019023 VENT VAPOUR OUTLET
$14.90
W0019081 FOOT ADJUSTABLE FRONT 60MM
$18.90
W0023533 ROLLER UPPER
$16.00
W0025794 O RING
W0025927 SWITCH MICRO DOOR
$35.00
W0047345 FILTER EMC
W0050183 SEAL NTC TURBIDITY
W0071618 SENSOR TEMPERATURE & TURBIDITY
W0071640 DETERGENT DISPENSER
W0071777 SPRAY ARM BOTTOM INCL VENTURI
W0071801 BASKET CUTLERY DARK GREY
W0071815 HOLDER COLUMN LOWER SPRAY ARM
W0071867 BUTTON CYCLE SILVER
W0071880 RACK CUP - DK GREY
W0071883 SPACER - DK GREY
W0071896 SPRAY ARM UPPER DARK GREY
W0072639 BRACE REAR UPPER
W0072645 LATCH.BRIDGING PLUG.COMPLETE
W0072653 CHANNEL DRAINAGE DARK GREY
W0072656 HOLDER PLINTH
W0072657 STIFFENING DOOR
W0072658 DOOR WHT ARCHED/60
W0072674 SIDE PANEL LEFT WHITE
W0072676 SIDE PANEL RIGHT WHITE
W0072685 TUBE PRESSURE SWITCH SAFETY
W0072693 HANDLE BRACKET
W0072694 CONTAINER CUP SMALL ELECTRONIC
$50.00
W0072725 SPONGE DRAIN PUMP 'L
$4.50
W0072731 DISHWASHER BASKET.BOTTOM.DARK
W0072812 SPRING DOOR HANDLE
$10.00
W0072851 AIR GUIDE - ACTIVE DRY
W0072882 WORKTOP
$93.50
W0072885 CONTROL PANEL ASSY SCREENED
W0072894 SUPPORT BRACKET MOTOR RUBBER
W0072898 PLINTH WHITE
W0072903 MANIFOLD HORIZONTAL DK GREY
$70.00
W0072904 SEAL BELLOWS CHANNEL DRAINAGE
$18.00
W0072906 FUNNEL FILLING D/W SALT TRANS
$6.00
W0072907 ROLLER BASKET ADJUSTMENT
W0072922 HANDLE CONTROL PANEL SILVER
W0090280 TIE HINGE
W0090328 GASKET. DECALCIFIER
W0090332 BRACKET ROLLER REAR SIFFENING
$10.00
W0090380 COVER WIRING
W0090402 SEALING STRIP
W0090423 NUT SPEED CLIP
W0090522 CROSSBAR FRONT UPPER
W0090544 PLATE SIDE - WHITE
W0090563 BASEPLATE BASEMENT
W0090569 PANEL BASE
W0090606 STOPPLE. DECALCIFIER ESL9163
W0090611 PLUG BRIDGING
$4.50
W0090612 CLAMP HOSE
W0090621 RING NUT. DECALCIFIER
W0090622 GASKET ANTI OVERFLOW
W0090626 DISCHARGE PIPE COMP X 2230MM
W0090627 GROMMET, DECALCIFIER ESL9163
$4.50
W0090636 COVER LATCH HOLE
W0090657 TRIM TUB BLACK
$30.00
W0090658 PIPE UNION. DECALCIFIER. SUMP
W0090726 CROSSBAR FRONT BOTTOM
W0090752 MICROSWITCH. ANTIOVERFLOW
W0090753 PIN HANDLE
W0090765 SPRING SIDE HANDLE
W0090773 HARNESS COMPLETE
W0090775 HOSE AIR DRYING L=680
W0090807 PUMP DRAIN
W0090830 ON/OFF BUTTON - SILVER
W0090835 VALVE SOLENOID WATER SOFTENER
W0090838 SALT SENSOR. DECALCIFIER. T&P
W0090839 FILTER MESH STAINLESS
$40.00
W0090851 FIXING CLAMP SENSOR
W0090859 DIFFUSER DISPLAY
W0116439 SERVICE KIT ELECTRIC CABLE
W0116854 HANDLE SIDE COMPLETE
W0127221 O RING MANIFOLD INNER
W0128153 NUT WATER DISTRIBUTOR
W0128154 DECALCIFIER COMPLETE ASSEMBLY
W0128208 CAPAC 3UF 450V 2PIN SPIGOT
$20.30
W0128257 INNER DOOR COMPLETE
$232.00
W0128314 HOSE INLET WATER BLOCK L=1800
W0128334 KIT SUPPORT FLOAT
$17.80
W0128356 SUPPORT ROLLER KIT PKT 4
$58.00
W0129222 SEAL AIR CHAMBER
W0149895 O RING SUMP
W0149952 BUFFER DISHWASHER BASKET
$8.00
W0153284 PCB CONFIGURED EDW1500
