EWF1495 — 914900045 00
ELECTROLUX — Washing Machine
Parts for EWF1495
W0016619 HOSE ELECTRIC VALVE CONT L=125
W0016838 DOOR FILTER ACCESS
W0016865 FILTER
W0016866 PROTECTION DOOR INTERLOCK
W0018724 SPRING SUSPENSION DRUM
W0025833 FIN INNER DRUM
$18.15
W0034761 HOSE INLET 2_5 D/W NUT/TAIL 2
W0071374 PULLEY G22/16
$33.40
W0074384 ELECTROLUX WASHING MACHINE DRAIN HOSE 2370mm LONG
W0133353 BEARING 30X72X19
$45.05
W0016561 SUPPRESSOR INTERFERENCE 16A
$48.85
W0016616 HOLDER SOLENOID
$8.15
W0016830 RING LOCKING
$8.80
W0016832 COVER FILTER
W0016868 DOOR GLASS
$49.05
W0018719 SEAL DRUM OUTER REAR
$27.30
W0025672 HANDLE DOOR KIT
$49.60
W0071353 VENT HOSE LONG
$22.00
W0071391 BELT 1184J6
W0074251 TUBE CONNECTOR
W0074253 BOLT CUSHION
W0074259 CLAMP HOSE
W0074262 STOPPER CAPACITOR CABLE
W0074264 SUPPORT HOSES REAR PANEL D
W0074267 DIFFUSER LAMP PORTHOLE
W0074286 ASSY CONVEYOR WATER
W0074296 SEAL
W0074322 BLOCK TERMINAL CONNECTOR
W0074339 SCREW BEARING SPIDER
W0074342 SCREW MAIN MOTOR
W0074369 SPRING PUSH BUTTON
W0074397 WASHER FRONT BOB
W0074414 DIFFUSER LAMP DOOR CATCH
W0074423 CLAMP HOSE
W0074434 HOOK DRAIN HOSE
W0074441 SUPPORT, CONTAINER, CARD
$10.00
W0074473 HOSE INLET (1300MM)
W0074481 LEG ASSY 30MM
W0074484 BRACKET HOSES & HARNESS
W0074488 SCREW FRONT BOB
W0074493 BASEMENT
W0074496 HOLDER LAMP
W0074502 CABLE. CLAMP. TUBE. REAR PANEL
W0074507 SYPHON ADDITIVES
W0074535 PLUG CABINET WHT
W0074541 SPACER HEATER ELEMENT G22
W0074574 SPRING RETAINING HEATER
$2.20
W0074578 SPRING DETERGENT DRAWER
W0074579 GROMMET HARNESS
W0074584 DISPENSER DETERGENT NEAT RIM
W0074596 DECORATION CABINET
W0074608 CONNECTOR 2 WAY
W0074610 ELECTRIC VALVE. 2 VIE EWF1495
W0074614 HOSE SOLENOID VALVE CONTAINER
W0074626 SEAL DRUM SHAFT G21 1600
W0074630 DELAYER KIT PORTHOLE
W0074752 PROGRAMME SELECTOR. EDR2000
W0074972 CUSHION. 80N ROSA PLAST
W0075541 SPRING FIXING
W0075547 HINGE ASSY
W0075612 BUTTON PUSH (PORTHOLE)
W0075623 A FRAME PORTHOLE (BACK)
W0075630 PIPE WATER OUTLET MANUAL DRAIN
W0075651 SEAL FILTER
W0075698 SWITCH PRESSURE ANALOGIC
W0075705 ELEMENT (1950 WATT)
W0075712 CABINET FRONT (WHITE)
W0075737 RECIRCULATION PUMP ASSY
W0075741 HOSE SUCTION CIRCULATION L=242
W0075745 COVER. DRAIN PUMP. CIRCULATION
W0075776 FOOT ASSY BACK 20MM
W0075798 CONTROLS SUPPORT. RIM/EWM2000
W0075814 WORK TOP
W0075819 SUPPORT TUBE CIRCULATION RIM
W0075822 LEG ADJUSTABLE ANTI VIBRATE
W0075823 SUPPORT SELECTOR JEWEL
W0075824 PROTECTION. HARNESS. X LCD
W0075825 PUSH BUTTON. JEWEL EWF1495
W0075826 SUPPORT. SEAL. PUSH BUTTON
W0075868 KNOB PROGRAMME SELECTOR WHT
$21.05
W0075877 PUMP DRAIN
W0075881 COVER INSPECTION PLATE
W0075886 SCREW. SHELL. TUB. 6. 5X50
W0075897 SWITCH PRESSURE AE+AE
W0075920 FRAME DOOR OUTER
$115.50
W0089105 DRUM ASSEMBLY G22 BD 1600
W0089110 SEALING. BELLOW. PORTHOLE
W0089113 MOTOR. INVERTER EWF1495
W0089116 DRAIN HOSE. TUB. MANIFOLD
W0089118 BELL. AIR. 2VIE EWF1495
W0089122 HOSE FILLER
W0089123 HOSE CIRCULATION DOOR
$42.00
W0089125 CABINET. BACK EWF1495
W0089128 ASSEMBLY. CARD. MOTOR CONTROL
W0089129 PCB. CONFIGURED. EWM3000NEW
W0089130 USER INTERFACE BOARD EWF1495
W0089132 ASSEMBLY. SHELL. BACK EWF1495
W0089137 ASSEMBLY. BODY. PUMP. G23
W0089152 TUBE. PRESSURE SWITCH. DUAL
W0089154 PANEL CONTROL ASSY
$77.90
W0089159 DAMPER VIBRATION EWF1495
W0089182 KIT. SHELL. COUNTERWEIGHT
W0089199 ASSEMBLY. SPIDER EWF1495
W0112897 CONTROL LAMP. ROSSA EWF1495
W0127410 DRAWER & SPRING ASSY DETERGENT
W0128096 BOLTS TRANSIT KIT
W0130193 SCREW M10 X 25 PULLEY CLAMPING
W0133356 BEARING 35X80X21
$62.00
W0134805 CABLE SUPPLY
