KSD25HWH — 956004534 00
KELVINATOR — Air-Conditioner

Parts for KSD25HWH

W0014920 MOTOR FAN INDOOR
W0019307 KELVINATOR AIRCON OUTDOOR TERMINAL & POWER PCB
W0019311 ELEC CONTROL BOX PCB ASSY
W0284450 REMOTE CONTROLLER
No image available
W0014917 MOTOR LOUVRE
No image available
W0015091 COMPRESSOR
No image available
W0015407 SENSOR TEMP ASSY DISCHARGE
No image available
W0015413 SENSOR PIPE TEMP ASSY
No image available
W0016446 FAN CROSS FLOW
No image available
W0016447 BLADE AXIAL FLOW
No image available
W0016451 FILTER AIR
$49.40
No image available
W0016453 FILTER AIR FRESHENING
$41.70
No image available
W0016454 FILTER AIR FRESHENING
$28.35
No image available
W0016455 HOSE DRAIN
$23.20
No image available
W0016456 JOINT DRAIN
$4.50
No image available
W0016468 LOUVRE VERTICAL
$29.05
No image available
W0016470 HOLDER BEARING
No image available
W0016473 CHASSIS ASSEMBLY
$263.80
No image available
W0016476 COVER CHASSIS RIGHT
$34.40
No image available
W0016481 COVER ELECTRONIC BOX
$9.85
No image available
W0016484 COVER FAN MOTOR
$91.75
No image available
W0016485 LOUVRE HORIZONTAL ASSEMBLY
$29.05
No image available
W0016488 COVER ELEC EQUIPMENT
$11.50
No image available
W0016490 COLLECTOR WATER
$57.35
No image available
W0016493 COVER CHASSIS LEFT
$34.40
No image available
W0016496 COVER ELECTRONIC CONTROL BOX
$6.05
No image available
W0016499 CLAMP PIPE BOARD
$6.50
No image available
W0016502 PANEL ASSEMBLY
No image available
W0016509 PLATE INSTALLATION
$305.05
No image available
W0016511 CHASSIS ASSEMBLY
$200.00
No image available
W0016515 PLATE MOUNTING PCB
$5.85
No image available
W0016516 COVER TOP ASSEMBLY
No image available
W0016517 PLATE VALVE
$34.40
No image available
W0016518 PARTITION BOARD ASSEMBLY
$45.85
No image available
W0016519 PANEL RIGHT ASSEMBLY
No image available
W0016766 SEAL RING
$4.50
No image available
W0016770 BASE BEARING
No image available
W0019119 VALVE ASSEMBLY LIQUID
No image available
W0019135 VALVE GAS (SUCTION)
$34.35
No image available
W0019141 VALVE LIQUID (DISCHARGE)
$25.35
No image available
W0019145 NUT , FLARE NUT 3/8 - 9.52mm
$6.25
No image available
W0019147 NUT, FLARE NUT 1/4 - 6.35mm
$4.50
No image available
W0019303 PCB MODULE DEMAND RESPONSE
No image available
W0019330 TERMINAL BLOCK
No image available
W0019332 WIRE ASSY COMPRESSOR
$24.50
No image available
W0282440 OUTDOOR MOTOR FAN - BRUSHLESS DC
No image available
W0282449 SENSOR TEMP ROOM
No image available
W0282452 SENSOR PIPE TEMPERATURE
$46.00
No image available
W0282490 CAP SCREW
$4.50
No image available
W0282497 PANEL FRAME ASSEMBLY
No image available
W0282535 NET, REAR
$35.05
No image available
W0282539 SUPPORT FAN MOTOR
$42.50
No image available
W0282852 MUFFLER ASSEMBLY
$55.00
No image available
W0282855 VALVE 4-WAY ASSEMBLY
No image available
W0282859 PIPE NUT
$4.00
No image available
W0282866 CONDENSER ASSEMBLY
No image available
W0282875 EVAPORATOR ASSEMBLY
$515.30
No image available
W0282893 ELEC CONTROL BOX PCB ASSY
No image available
W0282895 DISPLAY BOX ASSEMBLY
$113.15
No image available
W0284111 SENSOR TEMP ROOM
No image available
W0284115 HOLDER, REMOTE CONTROL
No image available
W0284177 HANDLE, BIG
$16.55
No image available
W0284372 GRILLE, AIR OUTLET
No image available
W0284375 PANEL, REAR LEFT PLATE ASSY
$73.70
No image available
W0284498 PANEL, FRONT ASSEMBLY
