KSV25HRG — 956002856 00
KELVINATOR — Air-Conditioner
Parts for KSV25HRG
W0014920 MOTOR FAN INDOOR
W0019307 KELVINATOR AIRCON OUTDOOR TERMINAL & POWER PCB
W0019311 ELEC CONTROL BOX PCB ASSY
W0014917 MOTOR LOUVRE
W0014919 MOTOR FAN OUTDOOR
W0015091 COMPRESSOR
W0015407 SENSOR TEMP ASSY DISCHARGE
W0015409 SENSOR AMBIANT TEMP ASSY
$49.35
W0015411 SENSOR AMBIENT TEMP ASSY
W0015413 SENSOR PIPE TEMP ASSY
W0015415 SENSOR PIPE TEMP ASSY
W0016446 FAN CROSS FLOW
W0016447 BLADE AXIAL FLOW
W0016451 FILTER AIR
$49.40
W0016452 FILTER AIR FRESHENING
W0016453 FILTER AIR FRESHENING
$41.70
W0016455 HOSE DRAIN
$23.20
W0016456 JOINT DRAIN
$4.50
W0016466 HOLDER, REMOTE CONTROL
W0016468 LOUVRE VERTICAL
$29.05
W0016470 HOLDER BEARING
W0016471 FRAME PANEL ASSEMBLY
$103.25
W0016473 CHASSIS ASSEMBLY
$263.80
W0016476 COVER CHASSIS RIGHT
$34.40
W0016481 COVER ELECTRONIC BOX
$9.85
W0016484 COVER FAN MOTOR
$91.75
W0016485 LOUVRE HORIZONTAL ASSEMBLY
$29.05
W0016488 COVER ELEC EQUIPMENT
$11.50
W0016490 COLLECTOR WATER
$57.35
W0016492 CAP SCREW
$4.50
W0016493 COVER CHASSIS LEFT
$34.40
W0016494 GRILLE AIR OUTLET
$45.00
W0016496 COVER ELECTRONIC CONTROL BOX
$6.05
W0016499 CLAMP PIPE BOARD
$6.50
W0016502 PANEL ASSEMBLY
W0016509 PLATE INSTALLATION
$305.05
W0016511 CHASSIS ASSEMBLY
$200.00
W0016514 COVER PCB OUTDOOR
W0016516 COVER TOP ASSEMBLY
W0016517 PLATE VALVE
$34.40
W0016518 PARTITION BOARD ASSEMBLY
$45.85
W0016519 PANEL RIGHT ASSEMBLY
W0016520 PANEL FRONT
W0016537 SUPPORT FAN MOTOR
$40.00
W0016766 SEAL RING
$4.50
W0016770 BASE BEARING
W0019116 VALVE 4-WAY ASSEMBLY
W0019119 VALVE ASSEMBLY LIQUID
W0019135 VALVE GAS (SUCTION)
$34.35
W0019141 VALVE LIQUID (DISCHARGE)
$25.35
W0019145 NUT , FLARE NUT 3/8 - 9.52mm
$6.25
W0019147 NUT, FLARE NUT 1/4 - 6.35mm
$4.50
W0019186 CONDENSER ASSEMBLY
$830.25
W0019188 EVAPORATOR ASSEMBLY
$395.00
W0019308 BOARD PCB DISPLAY BOX ASSY
W0019318 ELEC CONTROL BOX PCB ASSY
W0019326 REMOTE CONTROLLER
W0019330 TERMINAL BLOCK
W0019332 WIRE ASSY COMPRESSOR
$24.50
W0274358 HANDLE, BIG 'STEEL TYPE
W0274813 PCB WIFI BOX ASSY
$33.00
W0282454 NUT, FAN BLADE. OUTDOOR
$4.00
W0284375 PANEL, REAR LEFT PLATE ASSY
$73.70
