KTM3900WB*07
KELVINATOR — Fridge

Parts for KTM3900WB*07

W0018109 COVER HINGE RH
W0018222 FUSE THERMAL ASSY
W0019131 SCREW COUNTER SUNK THIMBLE
$4.50
W0083263 STOP DOOR
W0085292 WESTINGHOUSE ELECTROLUX FRIDGE DEFROST HEATER ELEMENT
W0085297 RELAY PTC STARTER
$55.00
W0085498 SHELF GLASS 599.92 X X344.79MM
W0085600 CAP LEG
$12.90
W0085609 LEG STABILISING
W0086637 HOSE DRAIN (SLIT 130MM)
$11.90
W0086638 BLADE FAN
W0086775 SWITCH LAMP
W0086833 WESTINGHOUSE FRIDGE DOOR BOTTOM HINGE PLATE R/H
W0086834 HINGE PLATE BOT LH BLACK ASSY
$34.50
W0086839 PAN DRAIN RJ422V
W0087127 BIN CRISPER
W0087130 DOOR DAIRY
W0087136 BIN CAN
$56.40
W0087145 BIN DOOR FZR
W0087213 HINGE TOP RH
W0087214 HINGE TOP LH
W0087302 TIMER DEFROST 8HR ROHS 7 MINUT
W0087327 THERMOSTAT DEFROST TERM
W0087368 THERMOSTAT - BLUE (ROHS)
$73.40
W0087464 ROLLER REAR GREY
W0087646 GASKET DOOR FC
$90.90
W0088096 MOTOR FAN EVAP
W0159670 DRIER 12GM(XH9)DBLE/SGLE TAIL
No image available
W0018042 BRACKET FAN MOTOR
$7.00
No image available
W0018049 CLIP SELF ADHESIVE
$9.00
No image available
W0018081 SHROUD FAN MOULDED RJ393V
No image available
W0018125 COVER HINGE LH
$12.95
No image available
W0018166 GROMMET FAN MOTOR
$16.45
No image available
W0018170 GROMMET COMPRESSOR
No image available
W0018253 CAP CORNER WHT
$17.05
No image available
W0018383 GASKET LAMP SEALING
$7.70
No image available
W0078982 STICKER WATTAGE 40W RS662V
No image available
W0081199 TIE CABLE 140MM LONG
No image available
W0081263 PIN COMPRESSOR MTG RS652M*6
No image available
W0082722 FOAM TAPE RJ393V
No image available
W0082742 CAP SCREW WHT
No image available
W0083235 CLIP-HEATER-ALUMINIUM BJ414Q
No image available
W0083869 PLUG DRAIN WHT
No image available
W0084491 SEAL BYPASS PLASTIC N410F
No image available
W0084558 DAMPER NOISE
No image available
W0084749 CLAMP-CORD BJ385T
No image available
W0085278 INSULATION EVAP COVER RJ393V
No image available
W0085299 BOX TERMINAL
No image available
W0085300 TERMINAL COVER RP342
No image available
W0085488 SHELF FREEZER RJ393V
No image available
W0085599 SPACER ROLLER STRIKESIDE RJ393
No image available
W0085622 TROUGH DRAIN SR300B
No image available
W0085638 COVER LAMP
$14.90
No image available
W0085702 ROLLER ADJUSTABLE RJ393V
No image available
W0085947 PLUG SCREW
$3.90
No image available
W0085992 DOOR ASSY FIP FC RH SR390C
No image available
W0085995 DOOR ASSY FIP FC LH WHT SR390C
$195.00
No image available
W0086053 THIMBLE FILLER ASSY CLOSED
No image available
W0086056 THIMBLE CAM ASSY CLOSED RJ393V
No image available
W0086131 COVER TOGGLE LOCK SR300B
No image available
W0086323 TRIM SHELF FREEZER 556MM
No image available
W0086339 SCREW M4 X 8 MUSH RJ393V
No image available
W0086441 GASKET DEL TOP N280J
No image available
W0086447 CAP
$12.90
No image available
W0086579 TAPE FOAM SEALING SBM3800MA
No image available
W0086607 SCREW 6GA 3/4 PAN PH BJ384V
No image available
W0086608 CORD SERVICE INSULATED
No image available
W0086769 EVAPORATOR ASSY
No image available
W0086829 EPS UPPER KTM3900M
No image available
W0086844 KNOB CONTROL KTM4200WA
No image available
W0087125 BIN BOTTLE ASSY STM3000WA
No image available
W0087143 BIN HALF WIDTH
No image available
W0087190 OVERLOAD T0366 GVT44
No image available
W0087325 CAPAC 4*0UF 400V WIRED CLIP
No image available
W0087402 SCREW 8/32 X 3/8 ETM3600WB
No image available
W0087403 CLIP MOUNTING COMPRESSOR
No image available
W0087405 SCREW 12/14 16MM ETM3600WB
No image available
W0087406 SCREW-HINGE/CAM-BTM ETM3600WB
$4.50
No image available
W0087407 SCREW 8/32 X 1/2THREAD FORMING
No image available
W0087409 SCREW EVAP COVER 8 X 1/2
$4.00
No image available
W0087411 SCREW HINGE CENTRE
$4.50
No image available
W0087412 SCREW ETM3600WB
No image available
W0087416 SCREW 8 X 1/2 T/F ETM3600WB
No image available
W0087417 NUT ETM3600WB
No image available
W0087422 LOCK WASHER ESE6108WA
No image available
W0087477 HINGE CENTRE N280J WHITE
No image available
W0087593 BASE PLATE COMP ASSY STM4200W
No image available
W0087642 GASKET DOOR FZR
No image available
W0087671 SHIELD LIGHT KTM3900MB
No image available
W0087721 COVER EVAP WTM4200PA
No image available
W0087731 HEAT SHIELD EVAP COVER
No image available
W0087735 TROUGH DRAIN WTM4200PA
No image available
W0087742 LAMP 40W SES 240V T25
No image available
W0087769 COM 134A GTT66 ELECTROLUX
No image available
W0087791 DOOR ASSY FIP FZR RH KTM4200WA
$253.30
No image available
W0087822 SHAFT ROLLER
$7.00
No image available
W0088119 HOUSING CTRL TOP ASSY KELV
No image available
W0088125 DOOR ASSY FIP FZR LH KTM3900WA
No image available
W0088179 LAMPHOLDER & HARNESS FZR
No image available
W0088213 HUMIDITY CONTROL KBM3800MB
No image available
W0088224 LID CRISPER ASSY (WATER CLEAR)
No image available
W0088226 EPS UPPER KTM3900M
No image available
W0088232 COVER EVAP ASSY EBM4307SC
No image available
W0088259 BADGE NAMEPLATE
No image available
W0134824 TAPE TESSA MOL 4761
No image available
W0134832 TAPE-FOAM SEAL18X4 14M/RLL.
