KVL6100B — 0W20011246
KENWOOD — Small Appliance
Parts for KVL6100B
W0277801 WHISK ASSEMBLY (12-WIRE)
W0357496 SPLASHGUARD ASSEMBLY
$18.00
W0358007 SHAFT ASSY CHEF CIRCLIP
$31.00
.jpg)
W0358341 KENWOOD DOUGH HOOK ALUMINIUM
$48.85
W0358766 KENWOOD STAINLESS STEEL 6.7L MIXING BOWL
$162.40
W0349086 HEAD RELEASE LATCH PLATE MIM
W0357067 SPIGOT SCREW 3PC
$12.90
W0357096 SLOW SPEED OUTLET O RING 3PC
$13.00
W0357112 WASHER PLASTIC 3PC
$13.20
W0357116 SPEED CONTROL RETAINING SPRING
$13.20
W0357127 GEARBOX MOUNT 4PC
$13.30
W0357146 HSO SPIGOT HSO GY34
$13.40
W0357172 CHASSIS DOWL 4PC
$13.70
W0357179 CORD ENTRY MOULDING PRINTED
$13.80
W0357189 LOCATION PIN
$13.80
W0357192 SSO ASSY O RING & SCREW
$13.80
W0357215 GEARBOX BOLT & WASHER SET 6PC
$13.90
W0357233 SPIGOT SEAT PLATE
$14.00
W0357243 MOTOR RETAINING SCREW AND BUSH SET
$14.10
W0357245 BODY COVER - NO PRINT
$14.10
W0357251 HINGE PIN & E CLIP
$14.20
W0357260 FOOT GREY GY43 - PACK 5
$14.30
W0357297 PCB & CORD HOUSING MOULDING
$14.60
W0357303 SPANNER
$14.60
W0357316 GEARBOX PULLEY & M8 NUT 2PC
$14.80
W0357326 BOWL SEAT PAD MAJOR 15CM
$14.90
W0357339 TIMING BELT
$15.00
W0357340 HEADLIFT SPRING
$15.00
W0357348 PCB & CORD HOUSING
$15.00
W0357361 PANET HUB SEAL SET
$15.20
W0357436 HUB NUT 3PC
$16.00
W0357476 HEADLIFT MICROSWITCH ASSY
$16.70
W0357555 SLOW SPEED OUTLET COVER ASSEMBLY
$19.00
W0357610 HEADLIFT LATCH ASSEMBLY
$19.30
W0357811 GEARBOX TOP MOUNT
$24.00
W0357888 HSO COVER ASSY
$26.20
W0357902 HIGH SPEED OUTLET COVER ASSEMBLY
$26.50
W0357906 HEADLIFT LEVER ASSEMBLY
$26.60
W0358109 CHASSIS
$33.00
W0358135 FOOT GREY 5PC
$34.30
W0358154 STALL PLUG
$35.30
W0358230 PCB ASSEMBLY
$38.60
W0358246 ASSIEME DI CONTROLLO DELLA VELOCITÀ
$39.20
W0358460 TOP COVER ASSY
$59.20
W0358521 MOTOR ASSEMBLY - 230V
$69.70
W0358626 GEARBOX ASSEMBLY WITHOUT PLANET HUB
$173.40
