WFE547SA — 940001823 25
WESTINGHOUSE — Cooker Electric

W0011112 ELEM CERAM 200 DIA 1800W (EGO)

W0011319 COVER GRILL DISH

W0011404 TRAY SCONE

$19.90

W0011922 HANDLE DOOR

$32.10

W0012254 ELEMENT C/HEAT 1800W SS321

W0012262 ELEMENT FAN RING 2200W

W0012326 CLIP MOUNTING ELEMENT

W0012570 END CAP HANDLE BLK WEST NGD

$14.05

W0012861 DOOR OVEN INNER GLASS

W0012990 SPACER HANDLE BLK FRESCO

$10.25

W0013596 SWITCH THERMAL CUT OUT 190 DEG

W0013627 TRIM DOOR UPPER VENTED

W0013702 TIMER 120 MINUTE WESTLAKE

W0013750 LENS INDICATOR LIGHT

$11.20

W0014040 SCREW 3/16X28 PAN PH TRILOB ZY

W0022807 HINGE DOOR OVEN

W0027342 GRILL DISH GIO ENAMEL

$105.45

W0029488 GRILL GRABBER FORTE

$4.50

W0032275 LAMP 25W 240V G9 PYRO HALOPIN

W0050403 MOTOR FAN OVEN

W0053487 SHELF OVEN 473 X 378MM

W0054725 SCRAPER CERAMIC GLASS

W0057166 CHEF SIMPSON WESTINGHOUSE COOKTOP CONTROL SWITCH MP101

W0057210 SWITCH AUXILIARY T/STAT

W0057771 THERMOSTAT OVEN

W0147339 SEAL OVEN MODULAR PROFILE

W0271174 IMPELLER OVEN FAN 160 MM

W0275063 LAMP OVEN ROUND PYRO BIOS

W0011114 TERMINAL BLOCK W/EARTH BIOS

W0011264 PLATE CVR TERM ELEC BIOS

$13.85

W0011388 SYNC GRILL SLIDE HANDLE FRESCO

$49.65

W0011461 PNL OUT OV DR ASS 540 WEST S/S

$175.50

W0011465 PNL OUT GR ASSY 540 WEST SS SM

$150.30

W0011625 PANEL CONTROL SCREEN WFE547SA

$146.35

W0011666 COVER FAN & ELEMENT

$95.75

W0011701 SPALSHBACK 540S/S FRESCO

$28.00

W0011845 HINGE GR DOOR 540 FRESCO PH2

$7.70

W0011846 HINGE GR DOOR 540 FREE FRESCO

$53.85

W0012315 CLIP THERMOSTAT BIOS

$9.00

W0012417 SUPPORT COUNTER FRESCO

$7.05

W0012911 CANOPY GRILL ELEC FRESCO

$27.50

W0012989 SPACER HANDLE SS FRESCO

W0013260 SHIELD WIRING

$11.95

W0013336 INSULATION GRILL BACK ELEVATED

$14.30

W0013342 INSUL GRILL CANOPY TOP FRESCO

$14.30

W0013460 BRACE OVEN REAR 540 BIOS

$27.50

W0013731 BUMPER STOP GREY

$5.05

W0014019 SCREW #6X3.5X28 HILO PAN PH

$4.50

W0014026 SCREW #8 X 5/16 CSK #2PH AB BK

$4.50

W0014029 SCREW #8 X 1/2 MUSH PH#2 AB BK

W0014030 SCREW #8 X 8MM HEX/MULTI

$4.50

W0014034 SCREW #8 X 1/2 MUSH #2PH AB BK

$4.50

W0014041 SCREW #8 x1/2 PH2 MUSH WASHER

$4.50

W0021318 SCREW M4X5 PHIL HZ

W0021330 NUT METRIC M10 X 0.75MM

W0021545 SPRING ELE CER GLOHO 540 EX HZ

$6.60

W0021773 PLT MTG SWTCH MULTI 7 SGO FRES

$14.30

W0021778 CERAMIC UNIT INDICATOR SHIELD

$11.00

W0021779 INDICATOR 4 HOTZONE T180

$17.10

W0021780 PANEL BASE 600 GIO

$168.50

W0022171 FOOT LEVELING

$16.35

W0029350 540 LOWER REAR BRACE

$12.60

W0029591 KNOB W/HOUSE 600FC S/S ELEC

W0029662 ANTI TILT PLATE

$15.65

W0029771 BRKT HOB MOUNT REAR 540FC ASSY

$15.10

W0029908 CABLE SERVICE CORD 20A FRESCO

$71.50

W0035788 DEFLECTOR HEAT GRILL UC20

W0039903 PANEL CABINET REAR (NO HOLE)

$28.00

W0043118 PANEL REFLECTOR GRILL TOP

W0044064 NUT M6 LH FAN MOTOR ECM

W0044830 FLUE DUCT OVEN ELEC 540 BIOS

W0047180 SUPPORT GRILL ELEMENT

W0048105 ENDCAP C/PANEL FRESCO S/S LHS

W0048106 ENDCAP C/PANEL FRESCO S/S RHS

W0052926 SPACER FOOT UC20

W0054645 INSULATION OVEN CABINET

W0054646 INSULATION OVEN BACK BIOS

W0064527 SCREW NO 8 X 12 MM PD

$4.50

W0064625 SCREW #8X20 TYP 17 PT TORX BLK

W0102437 HOB FRAME ASSY 540FC SS FRESCO

W0105318 SCREW

$7.35

W0109832 INDICATOR LIGHT NEON FRESCO

W0112555 ELEMENT CERAM DIA165 1200W EGO

W0114705 ELEM CER 230 D 2200/750W (S/L)

W0154046 SLIDER GRILL DOUBLE ACTION LH

$44.00

W0154047 SLIDER GRILL DOUBLE ACTION RH

$44.00

W0274177 PANEL SIDE GREY PRE PAINT

$54.10

W0275683 PLATE FOOT MOUNTING

W0275732 SWITCH INF/HEAT EGO DUO

W0275742 PANEL KICK 540 SML WHT PREPAIN

$25.05

W0275749 F/FRONT 540FC SEP GRILL

$46.05
