WLE535WA — 940001801 09
WESTINGHOUSE — Cooker Electric

W0011232 KNOB WEST 540 WHT RC ELEC FRES

W0011400 DISH GRILL ENAM SEP GRILL

$68.20

W0011404 TRAY SCONE

$19.90

W0011909 HANDLE GRILL DISH

$9.90

W0012254 ELEMENT C/HEAT 1800W SS321

W0012258 ELEMENT BOOST ASSY 800W - BIOS

W0012259 ELEMENT EGO 2000W 180DIA (HI)

W0012260 ELEMENT EGO 1000W 145DIA (HI)

$96.00

W0012570 END CAP HANDLE BLK WEST NGD

$14.05

W0012861 DOOR OVEN INNER GLASS

W0012990 SPACER HANDLE BLK FRESCO

$10.25

W0013554 SWITCH ROCKER SINGLE POLE WHT

W0013596 SWITCH THERMAL CUT OUT 190 DEG

W0013627 TRIM DOOR UPPER VENTED

W0014040 SCREW 3/16X28 PAN PH TRILOB ZY

W0022807 HINGE DOOR OVEN

W0046262 ELEMENT EGO 1500W 145DIA (HI)

W0046266 ELEMENT 1000W CL/HEAT + EARTH

W0046406 CLIP MOUNTING ELEMENT

W0053461 RACK GRILL INSERT

W0053487 SHELF OVEN 473 X 378MM

W0057166 CHEF SIMPSON WESTINGHOUSE COOKTOP CONTROL SWITCH MP101

W0057771 THERMOSTAT OVEN

W0060755 TIMER 60 MINUTE WESTLAKE

W0062420 LIGHT INDICATOR INC LENS

W0147339 SEAL OVEN MODULAR PROFILE

W0166032 LAMP 25W SES E14 300C CLEAR

$10.00

W0011114 TERMINAL BLOCK W/EARTH BIOS

W0011444 PNL OUT OV DR ASS 540 WEST FRE

$116.00

W0011450 PNL OUT GR ASSY 540 WEST LGE

W0011513 PANEL SIDE WHITE FRESCO

$89.30

W0011609 PNL CNT S/B SCR WLE535WA

$137.50

W0011929 HNDL DOOR WEST 7820 WHITE

$60.95

W0011993 NUT METRIC M10 X 0.75MM

$4.50

W0012315 CLIP THERMOSTAT BIOS

$9.00

W0012417 SUPPORT COUNTER FRESCO

$7.05

W0012522 SCREW M4 X 5 PAN #2PH SMALL HD

W0013260 SHIELD WIRING

$11.95

W0013262 SHIELD WIRING

$8.60

W0013266 SHIELD WIRING HOB INTERIM FRES

$31.90

W0013328 INSULATION OVEN BACK - KNAUF

$20.30

W0013460 BRACE OVEN REAR 540 BIOS

$27.50

W0013731 BUMPER STOP GREY

$5.05

W0013773 HOB S/BACK ENAM SOLID FRESCO

$139.60

W0014019 SCREW #6X3.5X28 HILO PAN PH

$4.50

W0014026 SCREW #8 X 5/16 CSK #2PH AB BK

$4.50

W0014029 SCREW #8 X 1/2 MUSH PH#2 AB BK

W0014030 SCREW #8 X 8MM HEX/MULTI

$4.50

W0014034 SCREW #8 X 1/2 MUSH #2PH AB BK

$4.50

W0024896 SPACER ALUMINIUM TUBE 6MM

$9.65

W0027189 F/FRONT PAINT 540RC SEP GRILL

$67.90

W0037440 PLATE REFLECTOR GRILL R/C

W0037482 PLATE ANTI TILT UPRIGHTS

W0038087 COVER WIRING ELEMENT SOLID

W0038121 COVER CLEAN HEAT FULL GALV BIO

W0038745 BRACKET ANTI ROTATE SOLID UC20

W0038835 BRACKET SUPPORT HOB 540RC

W0039903 PANEL CABINET REAR (NO HOLE)

$28.00

W0041113 PANEL LOWER BRACE 540

W0041132 PANEL KICK WHITE

W0042316 HINGE GR DOOR 540 FRESCO

$9.00

W0044830 FLUE DUCT OVEN ELEC 540 BIOS

W0045532 BOLT STABILISING

W0046271 SUPPORT ELEMENT BOOST

W0047180 SUPPORT GRILL ELEMENT

W0047469 SCREW M4 X 5 PAN #2 PH SML HD

$4.50

W0048101 ENDCAP REAR CONTROL PANEL RHS

W0048102 ENDCAP REAR CONTROL PANEL LHS

W0053471 RACK SIDE GRILL LH/RH

$59.10

W0054672 INSULATION OVEN WRAP - KNAUF

$63.85

W0056177 GRILL BOX ENAM 540 BIOS

W0056768 LEG LEVELLING

$18.90

W0056770 FOOT LEVELLING UPRIGHT

W0059836 DUCT GRILL BOX 540 R/C BIOS

W0064367 SCREW 3/16 X 1 PAN PHIL NI

W0064486 SCREW 3/16X28 PAN PH TRILOB BK

W0064747 NUT HEX 3/16 BSW

$4.50

W0064902 WASHER 1/4 EXT S/P

W0064939 WASHER 3/16 INT S/P ZC

$4.50

W0065222 CLAMP CABLE

W0065458 NUT HEX M6

$4.50

W0114680 HOLDER LAMP ASSY BIOS
