WVE615WC — 944031816 00
WESTINGHOUSE — Cooker Electric
Parts for WVE615WC

W0011406 TRAY BAKING SCONE - 468MM X 360MM

W0011995 NUT M6 LH FAN MOTOR
W0012256 ELEMENT GRILL/BOOST 3000W

W0012262 ELEMENT FAN RING 2200W
W0012326 CLIP MOUNTING ELEMENT
W0012886 GLASS OV DR IN WEST FORTE
W0013596 SWITCH THERMAL CUT OUT 190 DEG
W0022966 HINGE DOOR
W0030130 TRIM DOOR TOP CAP NGD

W0030434 SEAL OVEN MODULAR PROFILE

W0032275 LAMP 25W 240V G9 PYRO HALOPIN
W0050403 MOTOR FAN OVEN
W0057771 THERMOSTAT OVEN

W0271174 IMPELLER OVEN FAN 160 MM

W0011114 TERMINAL BLOCK W/EARTH BIOS

W0011201 SUPPORT ELEMENT GRILL VULCAN
$25.20

W0011264 PLATE CVR TERM ELEC BIOS
$13.85

W0011666 COVER FAN & ELEMENT
$95.75

W0011882 CHANNEL FRONT NGP UB RH
$16.90

W0013260 SHIELD WIRING
$11.95

W0013371 TAPE GASKA V1100 4.8 X 8 X 500

W0013461 BRACE OVEN REAR B/I BIOS
$24.85

W0013730 BUMPER STOP BLK
$6.55

W0013967 CLOCK 3 BTN TOUCH 'BF11' WHT

W0014019 SCREW #6X3.5X28 HILO PAN PH
$4.50

W0014030 SCREW #8 X 8MM HEX/MULTI
$4.50

W0014034 SCREW #8 X 1/2 MUSH #2PH AB BK
$4.50

W0014081 BUSH MOUNT F/FRAME V2 NGD
$5.05

W0022643 SCREW M4 X 4

W0027190 FRAME FRONT PAINTED ELE UB NGP
$62.95

W0030352 FAN COOLING ASSY RADIAL 11W

W0030457 PANEL SIDE UB BIOS RH
$49.15

W0030458 PANEL SIDE UB BIOS LH
$49.15

W0030490 PANEL TOP
$44.90

W0030494 PANEL BASE BIOS 0.5MM
$38.35

W0030606 INSULATION OVEN BACK - KNAUF
$15.55

W0042653 CHANNEL FRONT NGP UB LH

W0054672 INSULATION OVEN WRAP - KNAUF
$63.85

W0064527 SCREW NO 8 X 12 MM PD
$4.50

W0154077 ENDCAP CONTROL PANEL CHEF LHS

W0154078 ENDCAP CONTROL PANEL CHEF RHS

W0283213 SCREW M4 X 44 PAN T20

W0283384 SCREW #8 4.2 X 28 HILO PAN PH
$4.50

W0283441 COVER CLEAN HEAT
$9.65

W0283454 THERMAL CUTOUT 145 DEG N.C.

W0283463 BAG CONTAINING SCREWS BUILTINS
$4.50

W0283485 RACK SIDE OVEN EASY RH E100

W0283486 RACK SIDE OVEN EASY LH E100

W0284067 CLIP THERMOSTAT BIOS
$4.50

W0284351 DISH GRILL ENAM E100
$78.10

W0284441 ELEMENT BASE 1000W E100

W0296547 PANEL COVER WIRE UB E100
$34.75

W0361835 LENS SQUARE BLACK TRANSPARENT
$4.50

W0361860 LAMP OVEN ROUND DIA 48

W0361991 KNOB ASSY PAINTED ASPIRE
$17.40

W0361997 SPACER HANDLE ASPIRE

W0362001 HANDLE DR ANODISED ASPIRE

W0362013 PLATE MTG SWTCH SLCT CLOCK ASP
$31.35

W0362084 PNL OV DR OUT ASS WHT ASPIRE

W0362096 GLASS & CLIPS WVE615WC
$80.55

W0362115 RACK SHELF OVEN W/HOUSE

W0362116 RACK SHELF STEP DOWN W/HOUSE

W0362123 SWITCH MULTI 7 ASPIRE
$17.45

W0362140 RACK INSERT GRILL DISH ASPIRE

W0362237 MI SIGNAL LAMP 200/600MM SPARE
$17.20

W0362353 RACK PACK UB V3 ASPIRE
