WVEP916SC — 944031845 00
WESTINGHOUSE — Cooker Electric
Parts for WVEP916SC
W0011995 NUT M6 LH FAN MOTOR
W0012266 ELEMENT FAN RING 1200W VULCAN
.JPG)
W0012326 CLIP MOUNTING ELEMENT
W0012755 MOTOR FAN OVEN
W0014025 SCREW #8-10X35 PAN PH2 P/B BK
$4.50
W0026431 SPRING DAMPER MOTOR
$12.55
W0030169 ELEMENT GRILL SPLIT ELUX VUL
W0032275 LAMP 25W 240V G9 PYRO HALOPIN
_1.JPG)
W0050403 MOTOR FAN OVEN
W0271174 IMPELLER OVEN FAN 160 MM
W0011114 TERMINAL BLOCK W/EARTH BIOS
W0011201 SUPPORT ELEMENT GRILL VULCAN
$25.20
W0011264 PLATE CVR TERM ELEC BIOS
$13.85
W0011476 PANEL DECK GLUE ASS PYRO COBRA
$139.00
W0011502 PANEL BOTTOM BUILTIN VULCAN
$49.50
W0011507 PANELTOP BUILTIN VULCAN
$58.55
W0011695 PANEL FAN COVER
$112.55
W0011996 NUT M6 R/H FAN MOTOR
$5.30
W0012415 SUPPORT COUNTER LH
$9.35
W0012416 SUPPORT COUNTER RH
$9.35
W0012519 SCREW M4X5 HEX1/4' PH2 BLK ZP
$4.50
W0012667 INSTALL ANTI TILT HOOK
$13.90
W0012734 SEAL OVEN VULCAN PYRO
$69.90
W0012757 MOTOR FAN COOLING PYRO VULCAN
W0012806 STOP ANTI TILT
$3.30
W0013260 SHIELD WIRING
$11.95
W0013463 BRACE OVEN REAR VULCAN
$27.50
W0013649 GROMMET BUILTIN VULCAN
$8.00
W0013730 BUMPER STOP BLK
$6.55
W0014030 SCREW #8 X 8MM HEX/MULTI
$4.50
W0014034 SCREW #8 X 1/2 MUSH #2PH AB BK
$4.50
W0014041 SCREW #8 x1/2 PH2 MUSH WASHER
$4.50
W0014079 BUSH MOUNT F/FRAME NGD
$7.25
W0022974 RESISTOR 1050 OHM 20W PYRO
$58.40
W0022980 SHUTTLE +/-
$10.90
W0026349 HOUSING CENTRERING HELP
W0029882 CAP VENT DOOR TOP ASSY COBRA
$87.05
W0029930 GLASS OV DR MID 2 COBRA
W0030615 GLASS OV DR INNER BOROSILICATE
W0030616 GLASS OV DR MID1 REFL VULCAN
W0114251 DOOR LOCK ASSEMBLY
W0275660 HINGE SOFT CLOSE GENESYS
W0275756 PANEL RH SIDE BUILTIN VULCAN
$24.85
W0275757 PANEL LH SIDE BUILTIN VULCAN
$24.85
W0275765 IMPELLER OVEN FAN VULCAN R/H
$24.85
W0283096 SCREW M4 X 7 T20 ZINCSCREW M4
$4.50
W0283127 SWITCH 0+10 POSITION
$30.45
W0283213 SCREW M4 X 44 PAN T20
W0283381 INSULATION OVEN WRAP STD COBRA
$42.40
W0283384 SCREW #8 4.2 X 28 HILO PAN PH
$4.50
W0283485 RACK SIDE OVEN EASY RH E100
W0283486 RACK SIDE OVEN EASY LH E100
W0283609 CLEAN HEAT COVER E100 90CM
W0283672 INSULATION OVEN BACK E100 90CM
$16.65
W0283877 HANDLE PEDES TAUR+ 90CM ASPIRE
W0283878 HANDLE TAUR+ 90 ASPIRE BETTER
W0284064 CLIP SIDEGRIDS
$4.50
W0284345 ELEMENT C/H 1800W VULCAN E100
W0284366 SLIDE SINGLE EXT 1 SET
W0284573 FRAME FR ENA PYRO VULC BUILTIN
W0295025 LAMP OVEN HALOGEN 25W
$26.05
W0361882 PANEL BACK BUILTIN E100 90CM
$34.40
W0361896 WIRE HARNESS 90CM PR DR LOCK
$17.00
W0361978 CNTRLLR HEX WHT TOUCH PRG 916
W0361992 KNOB ASSY CHROME ASPIRE
W0362017 HARNESS HEXAGON CTRL INPUT
$4.60
W0362082 PNL CNT & CLIP WVEP916SC ASPIR
$204.60
W0362083 PLATE MTG SWT SET&HEX ASPIRE
$71.60
W0362087 PNL OV DR OUT ASS W/H BI PYRO
$168.25
W0362141 RACK INSERT ASPIRE 90CM
W0362179 RACK PACK ASPIRE 90CM
$139.30
W0362180 DISH GRILL ENAM DEEP ASPIRE 90
$81.60
W0362209 TRAY F/WIDTH ENAM ASPIRE 90
$78.20
W0362231 AIR FRYER ASSY ASPIRE 90CM
$99.80
