WVG613SNG — 944031704 00
WESTINGHOUSE — Cooker Gas
Parts for WVG613SNG
W0011127 BURNER OVEN BI BIOS
W0011237 KNOB ASSY WH BLDE SILVER FORTE
.JPG)
W0011297 BLADE FAN
W0011401 DISH GRILL ENAM F/WIDTH BIOS
W0011406 TRAY BAKING SCONE - 468MM X 360MM
W0011891 IGNITOR OVEN
.JPG)
W0011892 SENSOR FLAME
W0011995 NUT M6 LH FAN MOTOR
.JPG)
W0012255 ELEMENT GRILL 2200W SS321
.JPG)
W0012326 CLIP MOUNTING ELEMENT
W0012626 WIRE ASSY H/S DSI HV IGNITION
$36.20
W0012886 GLASS OV DR IN WEST FORTE
.JPG)
W0013590 SWITCH THERMAL CUT OUT 145 DEG
W0013687 HOSE FLEX 1.7M LONG BIOS-BI
$72.55
W0014025 SCREW #8-10X35 PAN PH2 P/B BK
$4.50
W0014032 SCREW #8 X 45 PAN QUADREX
.JPG)
W0022966 HINGE DOOR
W0023241 HOLDER LAMP ASSY BIOS
W0027133 VALVE SOLENOID GAS-20VDC DBL
W0045365 WASHER SEALING
$4.50
_1.JPG)
W0050403 MOTOR FAN OVEN
.JPG)
W0052585 CANOPY FAN ASSY U/B NGD
.JPG)
W0053530 SHELF OVEN
.JPG)
W0057771 THERMOSTAT OVEN
W0058493 TRIM DOOR UPPER VENTED
W0060747 TIMER 2 HR CUTOFF PEAPSA
W0063839 BOX IGNITION 1P DSI REIGN.
W0147339 SEAL OVEN MODULAR PROFILE
W0166032 LAMP 25W SES E14 300C CLEAR
$10.00
W0011198 SUPPORT IGNITION B/I BIOS
$15.55
W0011260 PLATE MOUNTING SWITCH
$14.95
W0011271 PLATE AERATION OVEN BURNER
$25.70
W0011317 COVER OVEN BURNER
$114.60
W0011472 PANEL DECK INTER GAS BIOS
$52.80
W0011479 PANEL TOP PYRO NGP
$43.20
W0011484 PANEL SIDE RH
$28.00
W0011485 PANEL SIDE LH
$27.50
W0011515 PANEL COVER WIRE UB 40MM
$24.20
W0011622 PNL CNT & CLIPS WVG613
$145.05
W0011671 PANEL FAN COVER
$112.55
W0011863 VENT GRILLE
$17.10
W0011931 HANDLE DOOR WEST SILVER FORTE
W0012315 CLIP THERMOSTAT BIOS
$9.00
W0012318 CLIP STAND-OFF 22MM-GAS BIOS
$11.70
W0012519 SCREW M4X5 HEX1/4' PH2 BLK ZP
$4.50
W0012562 MOUNT CAP F/FRAME R/H NGD
$5.80
W0012563 MOUNT CAP F/FRAME L/H NGD
$7.55
W0012578 STAND-OFF NON-PYRO WEST FORTE
W0012621 WIRE ELECTRICAL FLAME SENSE
W0012749 HOLDER INJECTOR OVEN BURNER
$12.20
W0012774 CORD SERVICE 10 A BIOS 1500MM
$34.90
W0013328 INSULATION OVEN BACK - KNAUF
$20.30
W0013330 INSULATION OVEN WRAP GAS BIOS
$41.80
W0013464 OVEN BRACE BI ASSY
W0013563 SWITCH MULTI 4 GAS BIOS
$45.00
W0013625 FRAME CONTROL PANEL
W0013730 BUMPER STOP BLK
$6.55
W0014018 SCREW #6 X 9.5MM PAN PHIL ZC
$4.50
W0014019 SCREW #6X3.5X28 HILO PAN PH
$4.50
W0014023 SCREW #8 X 5/8 CSK #2PH AB BK
$4.50
W0014029 SCREW #8 X 1/2 MUSH PH#2 AB BK
W0014030 SCREW #8 X 8MM HEX/MULTI
$4.50
W0014079 BUSH MOUNT F/FRAME NGD
$7.25
W0024929 INJECTOR GRILL 1.50MM
W0027192 FRAME FRONT PAINTED GAS UB NGP
W0027370 SCREW M4 X 25 PAN MTS PHIL BLK
$1.70
W0027378 LIGHT IND AMB 600MM
$8.50
W0029328 HOUSING LENS IND BIOS AMBER
$20.90
W0036213 SUPPORT ELEMENT GRILL
W0037478 PLATE CVR TERM GAS B/I BIOS
W0037480 PLATE SUPPORT VALVE BIOS
W0039602 PNL OV DR OUT ASS S/S FORTE
W0039639 BASEPLATE
W0042653 CHANNEL FRONT NGP UB LH
W0042654 CHANNEL FRONT NGP UB RH
W0043579 TUBE OVEN SUPPLY BIOS
W0044827 FLUE DUCT OVEN U/B GAS BIOS
W0047469 SCREW M4 X 5 PAN #2 PH SML HD
$4.50
W0052948 SPACER CONTROL PANEL BIOS
$6.00
W0053262 REG GAS NG INTEG T/PT & SEAT
$27.50
W0053308 STICKER GAS TYPE NG
$4.00
W0053490 RACK GRILL INSERT
W0053529 RACK SIDE SUPPORT OVEN EVOLVE
W0054086 SHIELD THERMO BULB BIOS
W0064592 SCREW TORQ #4 X 12 # PAN HEAD
W0065406 SCREW #8 X 3/4 STEPPED PAN BLK
W0065420 SCREW M4 X0.7X10 MUSH QUADRERX
