WVG655SLP — 944031676 25
WESTINGHOUSE — Cooker Gas
Parts for WVG655SLP
W0011127 BURNER OVEN BI BIOS
W0011237 KNOB ASSY WH BLDE SILVER FORTE
.JPG)
W0011297 BLADE FAN
W0011319 COVER GRILL DISH
W0011406 TRAY BAKING SCONE - 468MM X 360MM
W0011891 IGNITOR OVEN
.JPG)
W0011892 SENSOR FLAME
W0011932 HANDLE DR NP WEST ANOD FORTE
W0011995 NUT M6 LH FAN MOTOR
W0012254 ELEMENT C/HEAT 1800W SS321
.JPG)
W0012326 CLIP MOUNTING ELEMENT
W0012626 WIRE ASSY H/S DSI HV IGNITION
$36.20
W0012886 GLASS OV DR IN WEST FORTE
W0013569 AUXILIARY SW
$54.00
.JPG)
W0013590 SWITCH THERMAL CUT OUT 145 DEG
W0013687 HOSE FLEX 1.7M LONG BIOS-BI
$72.55
.JPG)
W0013966 WESTINGHOUSE OVEN CLOCK PCB 3 BUTTON TOUCH BF11
$126.00
W0014032 SCREW #8 X 45 PAN QUADREX
.JPG)
W0022966 HINGE DOOR
W0023201 HOLDER LAMP REAR HALOGEN BIOS
W0027133 VALVE SOLENOID GAS-20VDC DBL
W0029488 GRILL GRABBER FORTE
$4.50
W0032275 LAMP 25W 240V G9 PYRO HALOPIN
W0045365 WASHER SEALING
$4.50
_1.JPG)
W0050403 MOTOR FAN OVEN
.JPG)
W0057771 THERMOSTAT OVEN
W0058493 TRIM DOOR UPPER VENTED
W0063839 BOX IGNITION 1P DSI REIGN.
W0147339 SEAL OVEN MODULAR PROFILE
W0274109 SWITCH INF/HEAT EGO SINGLE
W0011198 SUPPORT IGNITION B/I BIOS
$15.55
W0011262 PLATE MOUNTING SWITCH
$14.90
W0011271 PLATE AERATION OVEN BURNER
$25.70
W0011289 SLIDE GRILL ASSY DOUBLE ACTION
W0011317 COVER OVEN BURNER
$114.60
W0011390 SLIDE BKT SGUB GRILL FORTE
$37.75
W0011472 PANEL DECK INTER GAS BIOS
$52.80
W0011479 PANEL TOP PYRO NGP
$43.20
W0011516 PANEL COVER WIRE SGUB 36MM
$59.40
W0011639 PNL CNT & CLIPS WVG655S
$161.00
W0011671 PANEL FAN COVER
$112.55
W0011845 HINGE GR DOOR 540 FRESCO PH2
$7.70
W0011846 HINGE GR DOOR 540 FREE FRESCO
$53.85
W0011863 VENT GRILLE
$17.10
W0011879 CHANNEL FRONT SGUB RH FORTE
$14.30
W0011880 CHANNEL FRONT SGUB LH FORTE
$14.30
W0012315 CLIP THERMOSTAT BIOS
$9.00
W0012318 CLIP STAND-OFF 22MM-GAS BIOS
$11.70
W0012519 SCREW M4X5 HEX1/4' PH2 BLK ZP
$4.50
W0012562 MOUNT CAP F/FRAME R/H NGD
$5.80
W0012563 MOUNT CAP F/FRAME L/H NGD
$7.55
W0012578 STAND-OFF NON-PYRO WEST FORTE
W0012621 WIRE ELECTRICAL FLAME SENSE
W0012749 HOLDER INJECTOR OVEN BURNER
$12.20
W0012774 CORD SERVICE 10 A BIOS 1500MM
$34.90
W0012885 GLASS OT SGUB GLUED WEST FORTE
$210.00
W0013321 INSULATION OVEN BACK - KNAUF
$41.80
W0013330 INSULATION OVEN WRAP GAS BIOS
$41.80
W0013333 INSULATION GRILL SGUB NGD
$14.30
W0013464 OVEN BRACE BI ASSY
W0013563 SWITCH MULTI 4 GAS BIOS
$45.00
W0013625 FRAME CONTROL PANEL
W0013730 BUMPER STOP BLK
$6.55
W0013733 STOP RUNNER
$8.15
W0014018 SCREW #6 X 9.5MM PAN PHIL ZC
$4.50
W0014023 SCREW #8 X 5/8 CSK #2PH AB BK
$4.50
W0014029 SCREW #8 X 1/2 MUSH PH#2 AB BK
W0014030 SCREW #8 X 8MM HEX/MULTI
$4.50
W0014031 SCREW #8 X 3/8 MUSH #2PH TC BK
$4.50
W0014034 SCREW #8 X 1/2 MUSH #2PH AB BK
$4.50
W0014041 SCREW #8 x1/2 PH2 MUSH WASHER
$4.50
W0014061 WASHER NYLON BLACK 3.7X 8X 0.8
$4.00
W0027318 FRAME FNT ENAM GAS SGUB FORTE
$79.20
W0027370 SCREW M4 X 25 PAN MTS PHIL BLK
$1.70
W0036213 SUPPORT ELEMENT GRILL
W0037478 PLATE CVR TERM GAS B/I BIOS
W0037480 PLATE SUPPORT VALVE BIOS
W0039212 DISH GRILL ENAM BIOS
$81.60
W0039639 BASEPLATE
W0043579 TUBE OVEN SUPPLY BIOS
W0044829 FLUE DUCT OVEN SGUB BIOS
W0046533 SLEEVE VIDAFLEX 16ID CUT 380MM
$16.50
W0046735 INJECTOR H/P 0.82MM
W0047469 SCREW M4 X 5 PAN #2 PH SML HD
$4.50
W0047803 ADAPTOR TEST POINT LP UC20
W0052586 CANOPY FAN ASSY SGUB NGD
W0053310 STICKER GAS TYPE LPG
$4.50
W0054086 SHIELD THERMO BULB BIOS
W0057758 THERMAL CUTOUT 100 DEG N.O.
W0059838 DUCT OVEN SGUB ASSY BIOS-GAS
W0064443 SCREW #8 X 3/8 #2PH AB
W0064592 SCREW TORQ #4 X 12 # PAN HEAD
W0065406 SCREW #8 X 3/4 STEPPED PAN BLK
W0065420 SCREW M4 X0.7X10 MUSH QUADRERX
W0147404 LIGHT INDICATOR AMBER LENS
W0154118 PNL OV DR OUT ASS S/S FORTE
