WBE5300WB-L — 925060547 01
WESTINGHOUSE — Fridge
Parts for WBE5300WB-L
W0018582 BADGE NAMEPLATE

W0020667 PCBA 3 LEDS CLUSTER GALAGA

W0027081 SCREW TRILOB M3X6
$4.50

W0027096 BOARD G SSLB WBE4500SA
$179.85

W0027222 TUBE PROCESS
$19.15

W0027439 SCREW TRILOB M5X16
$4.50

W0027460 BIN ICE

W0027522 COVER SCREW
$4.50

W0027560 GROMMET COMPRESSOR
$11.50

W0027562 CLAMP NTC EVAPORATOR

W0027610 CLAMP COMPRESSOR
$4.50

W0029435 TRAY EGG 80W

W0029558 HEATER RAD DEF R600 240V BF80W

W0029694 SHAFT ROLLER FRONT WTB4600
$7.60
W0029699 FOOT BASE THREAD
$8.75
W0029700 ROLLER FOOT
$17.10
W0029701 FOOT LEVER

W0147530 TRAY TWIST AND SERVE ASSY ICE

W0154021 PCB MAIN ERF2003 INTER DISPLAY

W0159670 DRIER 12GM(XH9)DBLE/SGLE TAIL

W0294684 SHROUD FAN ASSY BF DC 50HZ

W0295504 ELECTROLUX FRIDGE INVERTER PCB
$199.00

W0295505 MOTOR FAN DC 3W

W0018166 GROMMET FAN MOTOR
$16.45

W0020669 LENS 3 LEDS CLUSTER GALAGA
$26.80

W0027114 BASE COMP ASSY 70W RAYONG
$44.90

W0027119 SCREW TRILOB M6X18
$4.50

W0027401 BAFFLE MOTOR FBZA-1750-3D

W0027411 BLADE FAN,NAT
$32.25

W0027413 SEAL FOAM BOTTOM MF PINOT BF-N
$12.65

W0027441 SCREW TRUSS 4.2X13

W0027547 SHROUD FAN BF

W0027553 VALVE DRAIN ASSY BF
$184.20

W0027580 RAIL DOOR SUPPORT 80W WHT
$23.60

W0027602 GASKET FRZ BF80
$110.10

W0027604 GASKET FC BF80
$159.55

W0029308 DRAWER MIDDLE BODY BF80
$45.45

W0029310 HINGE TOP LEFT
$6.40

W0029375 SEALING MFLOW BACK BF 1725
$12.15

W0029377 DRAWER BODY BF80
$92.50

W0029398 DOOR BIN LOCKABLE TF80 WH ASSY

W0029406 DOOR BIN FLEX 80 WH-HOTFOIL

W0029412 DOOR BIN FC SHALL 80 WH-HOTFOI

W0029432 BIN DOOR FC BOTTLE TF80 EL

W0029433 DOOR BIN FINGER TF80 WH
$9.00

W0029446 SHELF FC TF80W
$79.80

W0029468 COVER TOP HINGE LEFT WHT
$12.95

W0029476 COVER GRID AIR RETURN BF
$4.50

W0029479 EPS EVAPORATOR BF 80
$149.15

W0029480 COVER SCREW MULTIFLOW LH
$4.50

W0029481 COVER SCREW MULTIFLOW RH
$4.50

W0029537 BEARING AUTO CLOSER L TF WHT
$8.80

W0029540 DRAWER LOWER BODY BF80
$48.00

W0029548 DRAWER FZR FR LWR ASY 80 WH
$64.00

W0029550 DRAWER FZR FR UPR ASY 80 WH
$63.65

W0029573 TRAY EVAP DRAIN BM/SD 80W
$38.45

W0029596 DRAIN PAN SD

W0029597 PAN DRAIN DYN CON

W0029603 REAR HOUSING PCB COVER
$164.80

W0029674 HINGE CENTRE BASE ASSY
$37.75

W0029675 HINGE CENTRE PIN SWING DOOR
$8.15

W0029697 COVER FOOT LEFT HINGE GREY
$12.95

W0029703 HINGE BASE LEFT ASSY
$29.00

W0029746 CRISPER SUPPORT LH
$17.75

W0029747 CRISPER SUPPORT RH
$17.75

W0029750 CRISPER COVER ASSY BF80 WH
$72.70

W0029761 BRACKET ICE MAKER
$14.50

W0029764 SUPPORT PASTRY SLIDE LH
$18.35

W0029814 SUPPORT PASTRY SLIDE RH
$14.00

W0029817 RETAINER CLIP
$4.50

W0029820 EPS FZ AIR STOPPER
$5.00

W0029843 TUBE CORRUGATE PF

W0029926 CRISPER GASKET 80
$22.00

W0030112 HEATER TUBE DRAIN PAN SD
$91.30

W0030113 SPACER 3 TURN HEATER
$4.50

W0030288 EVAPORATOR FF BF80
$144.45

W0030382 TUBE JUMPER H/X 80W EMBRACO
$7.25

W0147520 SWITCH DOOR
$26.50

W0147553 SHAFT ROLLER

W0154026 LENS COVER BLUE ASSY
$27.50

W0274142 ROLLER FIXED FOOT ASSY
$10.60

W0275285 SCREW (4,8X16 CP/C15)
$4.00

W0275459 MASTIC RUBBER T4MM
$16.05

W0275544 EXTENSION SLIDE ASSY LH 300MM

W0275545 EXTENSION SLIDE ASSY RH 300MM

W0275612 CLAMP COMPRESSOR SINGLE
$4.50

W0283829 DOOR SPARE FC WBE5300WB-L

W0283875 DOOR SPARE FZR WBE5300WB-L

W0295964 POWER CORD INV AU/NZ FERITE
$46.45

W0296466 EPS MULTIFLOW BF1725 WEST

W0296467 DRAWER FRONT BF80 FLAT WH ASSY

W0296478 PCBA UI 2ZONE WH BF INTL WHT
$91.80

W0296512 DISPLAY UI 2ZONE BF INT WHT
$101.55

W0358932 DRAWER PASTRY BODY BF 80 FLAT
$40.90

W0359364 COMPRESSOR

W0361765 COVER DEODORIZER

W0361766 MULTIFLOW ASSY WBE4500WB ML01

W0361779 COVER EVAPORATOR BF80 ASY 2-Z
$98.40

W0361782 DRAWER FZR FR MID ASY 80 WH FT
$68.00

W0361827 HARNESS-ASSY M/FLOW BF WEST
$36.55

W0361912 SENSOR HARNESS-ASSY FZR DEFROS

W0361970 GROMMET FAN PANA DC FAN
