WHE5204BC — 925060870 01
WESTINGHOUSE — Fridge
Parts for WHE5204BC
W0368405 ELECTROLUX WESTINGHOUSE FREEZER TWIST & SERVE ICE TRAY
$49.00
W0368416 SHROUD FAN ASSY BF DC 50HZ
$112.00
W0368451 EXTENSION SLIDE ASSY LH 300MM
$54.00
W0368452 EXTENSION SLIDE ASSY RH 300MM
$54.00
W0368463 ELECTROLUX WESTINGHOUSE FRIDGE FREEZER DEFROST SENSOR HARNESS
$24.95
W0368523 BIN ICE
$37.00
W0368660 HEATER RAD DEF R600 172W BF80W
$83.00
W0368856 ELECTROLUX WESTINGHOUSE FRIDGE FAN MOTOR DC 3W
$77.00
W0371546 BADGE NAMEPLATE
W0374188 BLADE FAN,NAT
W0365812 GROMMET COMPRESSOR
$14.00
W0365942 GROMMET FAN MOTOR
W0366097 SPRING FLIP MULLION MD
$10.00
W0366169 MAGNET SENSOR REED SW
$47.00
W0366316 LENS 3 LEDS CLUSTER GALAGA
$21.00
W0367406 SWITCH DOOR REED
W0367948 RETAINER CLIP
$4.00
W0367952 CLAMP COMPRESSOR SINGLE
$4.00
W0368021 SCREW TRUSS 4.2X13
$5.50
W0368023 CLAMP NTC EVAPORATOR
$4.50
W0368332 WESTINGHOUSE FRIDGE FLIP MULLION MD
$99.00
W0368335 DRAIN PAN SD
$33.00
W0368379 BEARING AUTO CLOSER L TF SL
$10.00
W0368381 SLIDER TELESCOPIC RAIL LH ASY
$216.00
W0368382 SLIDER TELESCOPIC RAIL RH ASY
$252.00
W0368404 SHROUD FAN BF
$90.00
W0368443 TRAY EGG 70W
$18.00
W0368469 FOOT LEVER
$10.00
W0368701 GASKET FRZ BF80
$116.00
W0368768 SHAFT TELESCOPIC RAIL WH80
$52.00
W0368818 PANEL UI PINOT WEST 2Z INTL
$46.00
W0368864 SCREW MOUNTING HANDLE MD36
$5.50
W0368866 DRIER 12GM(XH9)DBLE/SGLE TAIL
$30.00
W0368891 PCBA DRIVE EMBRACO FMXA9C
$237.00
W0368898 PAN DRAIN DYN CON
$26.00
W0368928 PCBA_RF2003 15W FCT PROGRAMED
$284.00
W0369890 COMPRESSOR PLATE, ASSEMBLY, 17
W0370027 SUPPORT PASTRY SLIDE LH
$21.00
W0370038 SUPPORT, DRAWER, RIGHT
W0370333 WASHER, FAN, SLINGER NYLON
W0371354 HARNESS-ASSY M/FLOW BF WEST
$42.00
W0371446 COVER FOOT LEFT HINGE GREY
$14.00
W0371448 FOOT BASE THREAD
$10.00
W0371464 COVER GRID AIR RETURN BF
$4.00
W0371482 ROLLER FIXED FOOT ASSY
$12.00
W0371545 EXTENSION SLIDE INSERT FZR RH
$10.00
W0371547 BAFFLE MOTOR FBZA-1750-3D
$94.00
W0371568 TUBE CORRUGATE PF
$18.00
W0372322 COVER SCREW MULTIFLOW RH
$4.00
W0372335 COVER MAGNET ENDCAP MD80 GR
$5.50
W0372362 COVER FOOT RIGHT HINGE GREY
$4.00
W0372363 TUBE PROCESS 100MM
$4.50
W0372369 SCREW 6X20 SELF TAPPING
$4.00
W0372378 CENTRE HINGE PIN DRAWER DOOR
$4.00
W0372381 CLAMP COMPRESSOR
$4.00
W0372387 SCREW-HINGE/CAM-BTM ETM3600WB
$4.50
W0372389 COVER SCREW MULTIFLOW LH
$4.00
W0372393 SCREW PF AB 3.5X1.27X19 PFZ PF
$4.00
W0372405 SPACER 3 TURN HEATER
$4.00
W0372453 BIN DOOR DAIRY LOCK TF
$4.45
W0372467 EPS FZ AIR STOPPER
$5.00
W0372513 BEARING HINGE FZR TOP OPEN
$7.00
W0372551 HINGE TOP LEFT
$8.00
W0372563 COVER TOP HINGE IW LH DG
$9.00
W0372577 SHAFT ROLLER FRONT WTB4600
$9.00
W0372590 HINGE TOP RIGHT
$10.00
W0372618 EXTENSION SLIDE INSERT FZR LH
$10.00
W0372686 TUBE JUMPER H/X 80W FMXY
$12.40
W0372687 SEALING MFLOW BACK BF 1725
$13.00
W0372697 SEAL FOAM BOTTOM MF PINOT BF-N
$14.00
W0372733 BIN DOOR DAIRY KNOB TF
$13.95
W0372735 BRACKET ICE MAKER
$16.00
W0372740 BIN DOOR DAIRY LID 70 EL-ART A
$14.50
W0372762 GROMMET FAN PANA DC FAN
$17.00
W0372768 LENS COVER BLUE ASSY
$16.60
W0372799 ROLLER FOOT
$19.00
W0372813 CRISPER SUPPORT LH
$17.70
W0372826 BEARING PAD
$21.00
W0372830 FOOT LEFT ASSY
$22.00
W0372831 FOOT RIGHT ASSY
$22.00
W0372852 CRISPER GASKET 80
$24.00
W0372876 BIN DOOR LOCKABLE BODY TF70 EL
$24.00
W0372912 POWERCORD INVERTER REF AU/NZ
$27.00
W0372953 TRAY EVAP DRAIN BM/SD 80W
$30.00
W0372992 BRACKET ADJUSTMENT BF IDP RH
$30.55
W0373000 BRACKET ADJUSTMENT BF IDP LH
$31.00
W0373017 HEATER TUBE DRAIN PAN SD LOK
$32.85
W0373069 BIN DOOR FINGER MD ASSY WH
$38.00
W0373078 HINGE CENTRE BASE ASSY
$40.00
W0373150 DRAWER PASTRY BODY BF 80 FLAT
$44.00
W0373169 DRAWER MIDDLE BODY BF80
$47.05
W0373226 BIN DOOR FC SHAL MD80 1-HOTFO
$58.00
W0373253 DRAWER TELESCOPIC RAIL WH80
$64.00
W0373263 BIN DOOR BOTTLE MD80 WH
$61.00
W0373276 DRAWER FRONT BF80 FLAT WH ASSY
$68.00
W0373278 DRAWER FZR FR UPR ASY 80 WH
$68.00
W0373279 DRAWER FZR FR MID ASY 80 WH
$68.00
W0373294 BIN DOOR FLEX 70 1-HOTFOIL
$68.00
W0373314 DRAWER FZR UPPER ASY 80 WH FT
$72.00
W0373336 CRISPER COVER ASSY BF80 WH
$77.00
W0373398 SHELF FC TF80W
$91.00
W0373400 PCBA UI 2ZONE FLAT SEA FD WHT
$86.00
W0373436 DRAWER FZR MID ASY 80 WH FLAT
$89.75
W0373467 COVER EVAPORATOR BF80 ASY 2-Z
$104.00
W0373484 GASKET FC MD80
$106.00
W0373487 CRISPER BODY ASSY BF80 WH
$98.00
W0373615 MULTIFLOW ASSY BF FLAT PINOT
$157.00
W0373618 EPS EVAPORATOR BF 80
$158.00
W0373628 EVAPORATOR FF BF80
$163.00
W0373647 REAR HOUSING PCB COVER
$173.00
W0373676 BOARD G SSLB WBE4500SA
$189.00
W0373684 VALVE DRAIN ASSY BF
$195.00
W0373694 DISPLAY UI WH 2ZONE FD INT WHT
$205.00
W0373867 HANDLE ASSY MD WH BLK
$436.00
W0373896 DOOR SPARE FZR WHE5204BB
$510.00
W0373959 DOOR SPARE FC L+R WHE5204BB
$814.00
