WTM5200WB*07
WESTINGHOUSE — Fridge
Parts for WTM5200WB*07
.JPG)
W0018080 HEATER DEFROST
W0018090 BIN FULL WIDTH
W0018093 BIN DOOR FZR
W0018096 BIN HALF WIDTH
.JPG)
W0018109 COVER HINGE RH
W0018128 BIN DELI DEEP
W0018222 FUSE THERMAL ASSY
W0018265 BIN CRISPER REAR
$89.05
.JPG)
W0018273 BIN ICE
W0018276 FACIA ASSY CRISPER
$44.95
W0018291 SUPPORT CENTRE
$15.85
W0019131 SCREW COUNTER SUNK THIMBLE
$4.50
W0020709 HOLDER BOTTLE WHT
$10.00
W0034671 TRAY ICE CUBE
.JPG)
W0083263 STOP DOOR
W0085297 RELAY PTC STARTER
$55.00
.JPG)
W0085600 CAP LEG
$12.90
W0085609 LEG STABILISING
W0086077 RUNNER RH
W0086637 HOSE DRAIN (SLIT 130MM)
$11.90
.JPG)
W0086638 BLADE FAN
.JPG)
W0086775 SWITCH LAMP
W0086833 WESTINGHOUSE FRIDGE DOOR BOTTOM HINGE PLATE R/H
W0086834 HINGE PLATE BOT LH BLACK ASSY
$34.50
W0086839 PAN DRAIN RJ422V
W0087029 BIN UTILITY LH 790
$67.90
W0087161 TRAY EGG
W0087213 HINGE TOP RH
W0087214 HINGE TOP LH
.JPG)
W0087302 TIMER DEFROST 8HR ROHS 7 MINUT
.JPG)
W0087327 THERMOSTAT DEFROST TERM
.JPG)
W0087361 THERMOSTAT CONTROL
W0087464 ROLLER REAR GREY
W0087741 LAMP 25W SES BLUE 240V E14
.JPG)
W0088096 MOTOR FAN EVAP
W0088144 BADGE WESTINGHOUSE
W0088487 STOP RAIL DELI BIN
W0159670 DRIER 12GM(XH9)DBLE/SGLE TAIL
W0018042 BRACKET FAN MOTOR
$7.00
W0018049 CLIP SELF ADHESIVE
$9.00
W0018078 SHROUD FAN MOULDED
$16.30
W0018125 COVER HINGE LH
$12.95
W0018126 RUNNER LH
W0018166 GROMMET FAN MOTOR
$16.45
W0018170 GROMMET COMPRESSOR
W0018253 CAP CORNER WHT
$17.05
W0018298 COVER HANDLE RH TOP LH BOT
$13.90
W0018299 COVER HANDLE LH TOP RH BOT
$13.90
W0018317 DOOR ASSY FIP FC RH WTM5200WB
$267.90
W0018318 DOOR ASSY FZR RH WH WTM5200WB
$226.00
W0018383 GASKET LAMP SEALING
$7.70
W0018502 FINGERS BOTTLE
$7.00
W0081199 TIE CABLE 140MM LONG
W0082722 FOAM TAPE RJ393V
W0082742 CAP SCREW WHT
W0083235 CLIP-HEATER-ALUMINIUM BJ414Q
W0083869 PLUG DRAIN WHT
W0084491 SEAL BYPASS PLASTIC N410F
W0084558 DAMPER NOISE
W0084619 STICKER MAX 25 WATTS N280J
W0084749 CLAMP-CORD BJ385T
W0085299 BOX TERMINAL
W0085300 TERMINAL COVER RP342
W0085340 EPS HOUSING CONTROL REAR RJ362
W0085341 BAFFLE CASING
W0085343 BAFFLE MANUAL CONTROLLED
W0085376 AIR CURTAIN RJ393V
W0085390 EPS CONTROL DEL AIR RJ362V
W0085461 KNOB LOCK
W0085462 LOCK LATCH
W0085494 INSULATION EVAP COVER RJ523V
W0085533 DOOR DAIRY RH RJ523V
W0085534 DOOR DAIRY LH RJ523V
W0085599 SPACER ROLLER STRIKESIDE RJ393
W0085630 SEALING MF RJ393V
W0085654 ROLLER CRISPER LID
W0085702 ROLLER ADJUSTABLE RJ393V
W0085947 PLUG SCREW
$3.90
W0086010 BIN BOTTLE RJ523V
W0086053 THIMBLE FILLER ASSY CLOSED
W0086056 THIMBLE CAM ASSY CLOSED RJ393V
W0086078 RUNNER CENTRE
$55.00
W0086339 SCREW M4 X 8 MUSH RJ393V
W0086395 KNOB CONTROL
$16.00
W0086441 GASKET DEL TOP N280J
W0086447 CAP
$12.90
W0086579 TAPE FOAM SEALING SBM3800MA
W0086608 CORD SERVICE INSULATED
W0086648 SHELF FC 699.92MM X X386.89MM
W0086789 HOUSING CONTROL
W0086996 SHIELD LAMP
W0087012 BIN CRISPER RH
$76.90
W0087023 HOUSING CONTROL TOP
W0087025 AIR CURTAIN
W0087026 AIR CURTAIN LID
W0087168 PAN DRAIN
$24.95
W0087175 GASKET DELIVERY FRONT
W0087189 LENS LIGHT FT527SA
W0087190 OVERLOAD T0366 GVT44
W0087325 CAPAC 4*0UF 400V WIRED CLIP
W0087334 PAD STOP SKID ROLLER
W0087383 EVAPORATOR ASSY
W0087402 SCREW 8/32 X 3/8 ETM3600WB
W0087403 CLIP MOUNTING COMPRESSOR
W0087405 SCREW 12/14 16MM ETM3600WB
W0087406 SCREW-HINGE/CAM-BTM ETM3600WB
$4.50
W0087407 SCREW 8/32 X 1/2THREAD FORMING
W0087409 SCREW EVAP COVER 8 X 1/2
$4.00
W0087410 SCREW DELI RUNNER RJ393V
W0087411 SCREW HINGE CENTRE
$4.50
W0087412 SCREW ETM3600WB
W0087416 SCREW 8 X 1/2 T/F ETM3600WB
W0087417 NUT ETM3600WB
W0087422 LOCK WASHER ESE6108WA
W0087457 HARNESS TIMER SBM3800MA
W0087477 HINGE CENTRE N280J WHITE
W0087594 BASE PLATE COMP ASSY STM5200WA
W0087652 GASKET DOOR FZR
W0087654 GASKET DOOR FC
W0087705 SHELF ASSY FZR
W0087720 COVER EVAP WTM5200PA
W0087727 LID CRISPER ASSY
W0087730 HEAT SHIELD EVAP COVER
W0087737 TROUGH DRAIN ASSY KTM5200WA
$24.95
W0087769 COM 134A GTT66 ELECTROLUX
W0087805 DOOR ASSY FIP FC LH WH WTM520
$268.90
W0087806 DOOR ASSY FZR LH WH WTM5200WB
$226.00
W0087822 SHAFT ROLLER
$7.00
W0088045 RUNNER DELI DEEP RH
W0088046 RUNNER DELI DEEP LH RJ443V
W0088054 BIN DAIRY
W0088180 LAMPHOLDER & HARNESS FZR
$44.90
W0088231 COVER EVAP ASSY EBM5107SC
W0088349 TRAY ICE CUBE ASSY
W0088463 PIN COMPRESSOR MTG WCM1500WC
W0134832 TAPE-FOAM SEAL18X4 14M/RLL.
W0163904 KNOB ICE B6565WTB2800WA-XAU
W0166429 SPRING ICE CUBE TRAY
